CENTRIC part description

Product Description

C-Tek Standard Brake Rotor

Features & Benefits

  • Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket

Product Attributes

Vane Style [cntrc] Straight
Weight [cntrc] Lbs 14.500
California Proposition 65 Text [cntrc] WARNING: Cancer and Reproductive Harm
Disc Mounting [cntrc] Floating
Misc Holes [cntrc] 4
Product Grade [cntrc] Standard
Weight [cntrc] Kgs 6.590
Discard Thickness 0.882 IN
Discard Thickness 22.400 MM
Nominal Thickness 24.000 MM
Nominal Thickness 0.945 IN
Overall Height 45.000 MM
Overall Height 1.772 IN
Outside Diameter 276.000 MM
Outside Diameter 10.866 IN
ABS Tone Ring Included No
Surface Type Smooth
Solid Or Vented Type Rotor Vented
Bearings Included No
Center Hole Diameter 69.000 MM
Center Hole Diameter 2.717 IN
Mounting Bolt Hole Circle Diameter 4.500 IN
Mounting Bolt Hole Circle Diameter 114.300 MM
Stud/Lug Hole Quantity 4
Stud/Lug Hole Diameter 0.496 IN
Stud/Lug Hole Diameter 12.600 MM

Additional Information

Harmonized Tariff Code (HTS) 8708305030
Harmonized Tariff Code (Schedule B) 8708300050
NAFTA Preference Criterion Code B
Country of Origin (Primary) CN
UPC 805890174837

Part Interchanges

CENTRIC 121.46035 Cross Reference

We have 4 alternatives for the 121.46035 by CENTRIC:

Fits Vehicles

  • Mitsubishi Galant (1991-1992)
