CENTRIC part description

Product Description

C-Tek Standard Brake Rotor

Features & Benefits

  • Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket

Product Attributes

Outer Bearing # [cntrc] 410.91002
Weight [cntrc] Kgs 5.230
Weight [cntrc] Lbs 11.500
Inner Seal # [cntrc] 417.45001
Disc Mounting [cntrc] Hub & Rotor
Product Grade [cntrc] Standard
California Proposition 65 Text [cntrc] WARNING: Cancer and Reproductive Harm
Inner Bearing # [cntrc] 410.91032
Misc Holes [cntrc] 0
Discard Thickness 12.000 MM
Discard Thickness 0.472 IN
Nominal Thickness 13.000 MM
Nominal Thickness 0.512 IN
Overall Height 95.700 MM
Overall Height 3.768 IN
ABS Tone Ring Included No
Surface Type Smooth
54 231.000 MM
Rotor Outside Diameter 9.094 in
Solid Or Vented Type Rotor Solid
Bolt Thread Pitch 1.500 MM
Bearings Included No
Center Hole Diameter 59.300 MM
Center Hole Diameter 2.335 IN
Mounting Bolt Hole Circle Diameter 110.000 MM
Mounting Bolt Hole Circle Diameter 4.331 IN
Mounting Bolt Hole Diameter 12.000 MM
Stud/Lug Hole Quantity 4

Additional Information

Harmonized Tariff Code (Schedule B) 8708300050
Harmonized Tariff Code (HTS) 8708305030
NAFTA Preference Criterion Code B
Country of Origin (Primary) CN
UPC 805890048367

Part Interchanges

CENTRIC 121.45005 Cross Reference

We have 6 alternatives for the 121.45005 by CENTRIC:

Fits Vehicles

  • Mazda 626 (1979-1982)
