(888) 312-8812 Login SignupC-Tek Standard Brake Rotor
| Disc Mounting [cntrc] | Floating / DIH |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Max Pb Drum Dia [cntrc] Mm | 230.800 |
| Weight [cntrc] Kgs | 8.640 |
| Vane Style [cntrc] | Straight |
| Misc Holes [cntrc] | 8 |
| Max Pb Drum Dia [cntrc] In | 9.087 |
| Weight [cntrc] Lbs | 19.000 |
| Product Grade [cntrc] | Standard |
| Discard Thickness | 16.000 MM |
| Discard Thickness | 0.630 IN |
| Nominal Thickness | 0.709 IN |
| Nominal Thickness | 18.000 MM |
| Overall Height | 102.400 MM |
| Overall Height | 4.031 IN |
| Outside Diameter | 329.500 MM |
| Outside Diameter | 12.972 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Nominal Drum Diameter | 230.000 MM |
| Nominal Drum Diameter | 9.055 IN |
| Bearings Included | No |
| Center Hole Diameter | 4.331 IN |
| Center Hole Diameter | 110.000 MM |
| Mounting Bolt Hole Circle Diameter | 5.890 IN |
| Mounting Bolt Hole Circle Diameter | 149.600 MM |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 16.500 MM |
| Stud/Lug Hole Diameter | 0.650 IN |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 805890252214 |
