(888) 312-8812 Login SignupC-Tek Standard Brake Rotor
| Vane Style [cntrc] | Straight |
| Misc Holes [cntrc] | 2 |
| Weight [cntrc] Lbs | 16.500 |
| Product Grade [cntrc] | Standard |
| Disc Mounting [cntrc] | Floating |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Kgs | 7.500 |
| Discard Thickness | 26.000 MM |
| Discard Thickness | 1.024 IN |
| Nominal Thickness | 28.000 MM |
| Nominal Thickness | 1.102 IN |
| Overall Height | 50.900 MM |
| Overall Height | 2.004 IN |
| Outside Diameter | 274.800 MM |
| Outside Diameter | 10.819 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 2.441 IN |
| Center Hole Diameter | 62.000 MM |
| Mounting Bolt Hole Circle Diameter | 114.300 MM |
| Mounting Bolt Hole Circle Diameter | 4.500 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 0.571 IN |
| Stud/Lug Hole Diameter | 14.500 MM |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 805890048121 |
| Brand | Part Number |
|---|---|
| 96340, BD125258 | |
| MAGMA PRODUCTS | PMR563050 |
| N/A | BD125258, 0802552, 0832552, 31117, BR31117, 121.44081, 64 79 950, 4351224061, 31117G, 106358, 4351224041, 141797, PRT1797, 128319, 4886340, 86340, 1094, JBR714, JBR714E, D17676, 1529024, 1.5290.2.4, 25849, X50917, BR1825, 96340, 96340R, 8922079, 78922079, 60075003 |
| PRONTO | BR31117 |
| RAYBESTOS | 96340, 96340R |
| WAGNER | BD125258 |
