(888) 312-8812 Login SignupC-Tek Standard Brake Rotor
| Misc Holes [cntrc] | 1 |
| Product Grade [cntrc] | Standard |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Vane Style [cntrc] | Straight |
| Weight [cntrc] Lbs | 25.300 |
| Disc Mounting [cntrc] | Floating |
| Weight [cntrc] Kgs | 11.500 |
| Discard Thickness | 27.400 MM |
| Discard Thickness | 1.079 IN |
| Nominal Thickness | 1.173 IN |
| Nominal Thickness | 29.800 MM |
| Overall Height | 83.000 MM |
| Overall Height | 3.268 IN |
| Outside Diameter | 315.200 MM |
| Outside Diameter | 12.409 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 3.346 IN |
| Center Hole Diameter | 85.000 MM |
| Mounting Bolt Hole Circle Diameter | 130.000 MM |
| Mounting Bolt Hole Circle Diameter | 5.118 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 15.100 MM |
| Stud/Lug Hole Diameter | 0.594 IN |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 805890517801 |
