Quality-Built Disc Brake Rotor - Black Series, Coated

Product Description

Quality-Built Black Series Coated Rotor

Application Summary

Scion iQ 2013, Toyota Prius C 2019-2012, Yaris 2018-2006

Features & Benefits

  • OE Style Symmetric Vane Designs
  • Non-directional friction surfaces
  • Precision machined mounting surfaces
  • Installation-ready without cleaning
  • Q-Shield Protective Coatings
  • High-Carbon Metullargy
  • G11H18 Alloys
  • Mill balanced
  • Straddle Cut to eliminate DTV

Black Series Brake Rotor, Brake Rotor, MPA Brake Rotot, Quality-Built Brake Rotor, Coated Rotor, Black Coated Rotor

Product Attributes

Finish Coated
Product Condition New
Discard Thickness 19.0 MM
Discard Thickness 0.7 IN
Nominal Thickness 22.0 MM
Nominal Thickness 0.9 IN
Disc Finish Coated
Hat Finish Coated
Rust Resistant Coating Yes
Outside Diameter 255.0 MM
Outside Diameter 10.0 IN
Grade Type Regular
ABS Tone Ring Included No
Surface Type Smooth
Solid Or Vented Type Rotor Vented
Bearings Included No
Center Hole Diameter 55.0 MM
Mounting Bolt Hole Circle Diameter 100.0 MM
Mounting Bolt Hole Circle Diameter 3.937 IN
Mounting Bolt Hole Diameter 0.571 IN
Mounting Bolt Hole Diameter 14.5 MM
Stud/Lug Hole Quantity 4

Additional Information

Harmonized Tariff Code (Schedule B) 8708300050
NAFTA Preference Criterion Code B
Country of Origin (Primary) CN
Harmonized Tariff Code (HTS) 8708305030
UPC 00190037433503

Fits Vehicles

  • Scion iQ (2013)
  • Toyota Prius C (2012-2019)
  • Toyota Yaris (2006-2018)
