CENTRIC 120.80016 Part Description
Manufacturer
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
CENTRIC 120.80016 Specifications
Product Attributes
| Disc Mounting [cntrc] | Floating |
| Vane Style [cntrc] | Straight |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Notes [cntrc] | Hat Shaped |
| Misc Holes [cntrc] | 0 |
| Weight [cntrc] Kgs | 17.050 |
| Weight [cntrc] Lbs | 37.500 |
| Product Grade [cntrc] | Premium |
| Discard Thickness | 1.320 IN |
| Discard Thickness | 33.530 MM |
| Nominal Thickness | 36.580 MM |
| Nominal Thickness | 1.440 IN |
| Overall Height | 2.898 IN |
| Overall Height | 73.600 MM |
| Outside Diameter | 384.000 MM |
| Outside Diameter | 15.118 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 5.402 IN |
| Center Hole Diameter | 137.200 MM |
| Mounting Bolt Hole Circle Diameter | 6.417 IN |
| Mounting Bolt Hole Circle Diameter | 163.000 MM |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 16.510 MM |
| Stud/Lug Hole Diameter | 0.650 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 805890361602 |
CENTRIC 120.80016 Cross References
CENTRIC 120.80016 Fits Vehicles
- Workhorse P30 (2000-2005)
- GMC P3500 (1998-1999)
- Chevrolet P30 (1998-1999)
