Centric 120.80016 - Centric Premium Brake Rotor
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
CENTRIC part description
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
Product Attributes
| Disc Mounting [cntrc] | Floating |
| Vane Style [cntrc] | Straight |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Notes [cntrc] | Hat Shaped |
| Misc Holes [cntrc] | 0 |
| Weight [cntrc] Kgs | 17.050 |
| Weight [cntrc] Lbs | 37.500 |
| Product Grade [cntrc] | Premium |
| Discard Thickness | 1.320 IN |
| Discard Thickness | 33.530 MM |
| Nominal Thickness | 36.580 MM |
| Nominal Thickness | 1.440 IN |
| Overall Height | 2.898 IN |
| Overall Height | 73.600 MM |
| Outside Diameter | 384.000 MM |
| Outside Diameter | 15.118 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 5.402 IN |
| Center Hole Diameter | 137.200 MM |
| Mounting Bolt Hole Circle Diameter | 6.417 IN |
| Mounting Bolt Hole Circle Diameter | 163.000 MM |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 16.510 MM |
| Stud/Lug Hole Diameter | 0.650 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 805890361602 |
Part Interchanges
CENTRIC 120.80016 Cross Reference
We have 3 alternatives for the 120.80016 by CENTRIC:
Fits Vehicles
- Workhorse P30 (2000-2005)
- GMC P3500 (1998-1999)
- Chevrolet P30 (1998-1999)
