Centric 120.66052 - Centric Premium Brake Rotor
$7349
MSRP: $91.46
Save: $17.97
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
Product Attributes
| Disc Mounting [cntrc] | Floating / DIH |
| Max Pb Drum Dia [cntrc] Mm | 211.700 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Kgs | 8.180 |
| Vane Style [cntrc] | Straight |
| Misc Holes [cntrc] | 2 |
| Max Pb Drum Dia [cntrc] In | 8.335 |
| Weight [cntrc] Lbs | 18.000 |
| Product Grade [cntrc] | Premium |
| Discard Thickness | 18.500 MM |
| Discard Thickness | 0.728 IN |
| Nominal Thickness | 0.787 IN |
| Nominal Thickness | 20.000 MM |
| Hat Finish | Coated |
| Overall Height | 85.000 MM |
| Overall Height | 3.346 IN |
| Outside Diameter | 325.000 MM |
| Outside Diameter | 12.795 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Nominal Drum Diameter | 210.200 MM |
| Nominal Drum Diameter | 8.276 IN |
| Bearings Included | No |
| Center Hole Diameter | 3.098 IN |
| Center Hole Diameter | 78.700 MM |
| Mounting Bolt Hole Circle Diameter | 127.000 MM |
| Mounting Bolt Hole Circle Diameter | 5.000 IN |
| Stud/Lug Hole Quantity | 6 |
| Stud/Lug Hole Diameter | 13.200 MM |
| Stud/Lug Hole Diameter | 0.520 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 805890075196 |
Part Interchanges
- Raybestos Brakes 580029
- Raybestos Brakes 580029FZN
- Raybestos Brakes 580029R
- Neotek Premium Drums and Rotors 107281GF
- BD126590
- BD126029
- BD126029E
- E125-71-057
- BR5507302
- 6493275
- 55073
- 55073G
- 19175173
- 19241818
- 8151589750
- 15134671
- 15158975
- 145314
- 101758
- 48880029
- 880019
- 880029
- AR8647
- E12571057
- 55073HC
- 120.66052
- 55073GT
- 15091843
- 15158976
- 1407-25836
- YH145314
- 27283
- 580029P
- 2055073
- 19958
- 90048045
- 177882
- 18A1207
- 18A1207A
CENTRIC 120.66052 Cross Reference
We have 7 alternatives for the 120.66052 by CENTRIC:
Fits Vehicles
- Chevrolet Trailblazer EXT (2002-2006)
- GMC Envoy XL (2002-2006)
- GMC Envoy XUV (2004-2005)
- Oldsmobile Bravada (2002-2004)
- Chevrolet SSR (2003-2006)
- Chevrolet Trailblazer (2002-2009)
- GMC Envoy (2002-2009)
- Saab 9-7x (2005-2009)
- Buick Rainier (2004-2007)
- Isuzu Ascender (2003-2008)
