(888) 312-8812 Login SignupDELPHI TC7869 Ball Joint
Tap to view 15 more
$2199
Limited availability at this price!
In Stock
Get it by Thursday, Dec 18
DELPHI TC7869 Part Description
Ball Joint
DELPHI TC7869 Specifications
Product Attributes
| Position(s) | Front Upper |
| Material | Steel |
| Maximum Outside Diameter | 2.402 IN |
| Maximum Outside Diameter | 61.00 MM |
| Color | Gray |
| Stud Thread Diameter | 12 MM |
| Castle Nut Included | No |
| Grease Fitting Included | No |
| Bushings Included | No |
| Dust Boot Included | Yes |
| Width | 56 MM |
| Cotter Pin Included | No |
| Cotter Pin Hole | No |
| Mounting Hardware Included | Yes |
| Washers Included | No |
| Height | 4.803 IN |
| Height | 122.00 MM |
| Nuts Included | Yes |
| Adjustable | No |
| Greaseable | No |
| Stud Thread Length | 1.614 IN |
| Stud Thread Length | 41 MM |
| Stud Type | Threaded |
| Mounting Type | Press-In |
| Dust Boot Material | Rubber |
| Mounting Bolts Included | No |
| Mount Plate Included | No |
| Tapered Stud | Yes |
| Stud Tapered End 2 Diameter | 0.776 IN |
| Stud Tapered End 2 Diameter | 19.7 MM |
| Stud Tapered End 1 Diameter | 0.646 IN |
| Stud Tapered End 1 Diameter | 16.4 MM |
| Stud Thread Pitch | 1.75 MM |
| Length | 122.00 MM |
| Length | 4.800 IN |
| Stud Thread Diameter | 0.47 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708806590 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Harmonized Tariff Code (Schedule B) | 8708807000 |
| Country of Origin (Primary) | TR |
| UPC | 00689604378250 |
| VMRS Code | 016001014 |
| UNSPSC | 25174203 |
DELPHI TC7869 Part Interchanges
| Brand | Part Number |
|---|---|
| MOOG Chassis Products | K500359 |
| Ford | FL3Z 3084-B |
| Dorman | 527-050, CB85228, CB85228PR |
| N/A | TXMS40546, K500422 |
DELPHI TC7869 Fits Vehicles
- Lincoln Navigator (2018-2020)
- Ford Expedition (2018-2020)
- Ford F-150 (2015-2020)
DELPHI TC7869 Manufacturer Information
Delphi® is committed to making a difference. With a global network of more than 2,400 service centers and a presence in over 150 countries, Delphi Technologies delivers OE-specific aftermarket parts and software solutions for a wide range of passenger vehicles, light and medium commercial vehicles, heavy-duty truck and commercial vehicles, as well as agricultural, marine, and industrial equipment. The company’s comprehensive product portfolio includes components for diesel fuel systems, engine management, gasoline fuel systems, vehicle electronics, and maintenance solutions. Delphi Technologies takes pride in its state-of-the-art manufacturing facility as well as OE-level diagnostic and test equipment that produces OE-quality aftermarket components to make vehicles and trucks run cleaner, drive better, and last further.
