Centric 120.65106 - Centric Premium Brake Rotor
$8699
MSRP: $103.10
Save: $16.11
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
Product Attributes
| Misc Holes [cntrc] | 0 |
| Weight [cntrc] Lbs | 20.500 |
| Disc Mounting [cntrc] | Floating / DIH |
| Max Pb Drum Dia [cntrc] Mm | 207.200 |
| Vane Style [cntrc] | Straight |
| Max Pb Drum Dia [cntrc] In | 8.157 |
| Product Grade [cntrc] | Premium |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Kgs | 9.320 |
| Discard Thickness | 20.400 MM |
| Discard Thickness | 0.803 IN |
| Nominal Thickness | 0.866 IN |
| Nominal Thickness | 22.000 MM |
| Hat Finish | Coated |
| Overall Height | 75.600 MM |
| Overall Height | 2.976 IN |
| Outside Diameter | 331.000 MM |
| Outside Diameter | 13.031 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Nominal Drum Diameter | 205.900 MM |
| Nominal Drum Diameter | 8.106 IN |
| Bearings Included | No |
| Center Hole Diameter | 87.600 MM |
| Center Hole Diameter | 3.449 IN |
| Mounting Bolt Hole Circle Diameter | 139.700 MM |
| Mounting Bolt Hole Circle Diameter | 5.500 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 15.300 MM |
| Stud/Lug Hole Diameter | 0.602 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 805890311713 |
Part Interchanges
CENTRIC 120.65106 Cross Reference
We have 7 alternatives for the 120.65106 by CENTRIC:
Fits Vehicles
- Ford Econoline (2006)
- Ford E-150 Club Wagon (2004-2005)
- Ford E-150 (2004-2006)
