(888) 312-8812 Login SignupCENTRIC 120.65074 Centric Premium Brake Rotor
Tap to view 4 more
$31249
Limited availability at this price!
In Stock
Get it by Thursday, Feb 5
CENTRIC 120.65074 Part Description
Manufacturer
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
CENTRIC 120.65074 Specifications
Product Attributes
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Inner Race # [cntrc] | 416.68003 |
| Weight [cntrc] Lbs | 56.100 |
| Inner Bearing # [cntrc] | 415.68004 |
| Outer Bearing # [cntrc] | 415.68002 |
| Misc Holes [cntrc] | 0 |
| Disc Mounting [cntrc] | Hub & Rotor |
| Outer Race # [cntrc] | 416.68001 |
| Inner Seal # [cntrc] | 417.65003 |
| Weight [cntrc] Kgs | 25.500 |
| Product Grade [cntrc] | Premium |
| Vane Style [cntrc] | Pillar |
| Discard Thickness | 36.000 MM |
| Discard Thickness | 1.417 IN |
| Nominal Thickness | 38.000 MM |
| Nominal Thickness | 1.496 IN |
| Hat Finish | Coated |
| Stud Thread Diameter | 14.000 MM |
| Overall Height | 232.200 MM |
| Overall Height | 9.142 IN |
| ABS Tone Ring Included | Yes |
| Surface Type | Smooth |
| Rotor Outside Diameter | 331.000 MM |
| Rotor Outside Diameter | 13.031 in |
| Solid Or Vented Type Rotor | Vented |
| Bolt Thread Pitch | 2.000 MM |
| Bearings Included | No |
| Center Hole Diameter | 125.000 MM |
| Center Hole Diameter | 4.921 IN |
| Mounting Bolt Hole Circle Diameter | 170.000 MM |
| Mounting Bolt Hole Circle Diameter | 6.693 IN |
| Stud/Lug Hole Quantity | 8 |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| UPC | 805890015413 |
CENTRIC 120.65074 Cross References
| Brand | Part Number |
|---|---|
| 66768, BD125651 | |
| N/A | BD125651, E125-70-079, 54076, 54076G, 1C3Z1V102BA, F81A1102DB, F81A1102MA, F81Z1102DB, F81Z1102DC, F81Z1102MA, 102891, 145267, 86768, 86785, 4886768, AR8574, AR8575, E12570079, E12354, YC351102C, 3C341102C, 130795, 13079501, YH145267, 1407-25821, 27265, 19922, 8942074, 8942075, 60054164 |
| NEOTEK | 107190GF |
| Neotek Premium Drums and Rotors | 107190GF |
| RAYBESTOS | 66768, 66768R |
| Raybestos Brakes | 66768, 66768R |
| WAGNER | BD125651 |
CENTRIC 120.65074 Fits Vehicles
- Ford F-350 Super Duty (1999-2002)
