(888) 312-8812 Login SignupCENTRIC 120.65071 Centric Premium Brake Rotor
Tap to view 4 more
MSRP: $121.40
$8349
Save $37.91
Limited availability at this price!
In Stock
Get it by Wednesday, Jan 7
CENTRIC 120.65071 Part Description
Manufacturer
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
CENTRIC 120.65071 Specifications
Product Attributes
| Max Pb Drum Dia [cntrc] In | 8.157 |
| Product Grade [cntrc] | Premium |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Kgs | 10.910 |
| Vane Style [cntrc] | Pillar |
| Misc Holes [cntrc] | 0 |
| Weight [cntrc] Lbs | 24.000 |
| Disc Mounting [cntrc] | Floating / DIH |
| Max Pb Drum Dia [cntrc] Mm | 207.200 |
| Discard Thickness | 28.000 MM |
| Discard Thickness | 1.102 IN |
| Nominal Thickness | 1.181 IN |
| Nominal Thickness | 30.000 MM |
| Hat Finish | Coated |
| Overall Height | 3.878 IN |
| Overall Height | 98.500 MM |
| Outside Diameter | 325.900 MM |
| Outside Diameter | 12.831 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Nominal Drum Diameter | 205.000 MM |
| Nominal Drum Diameter | 8.071 IN |
| Bearings Included | No |
| Center Hole Diameter | 127.000 MM |
| Center Hole Diameter | 5.000 IN |
| Mounting Bolt Hole Circle Diameter | 170.000 MM |
| Mounting Bolt Hole Circle Diameter | 6.693 IN |
| Stud/Lug Hole Quantity | 8 |
| Stud/Lug Hole Diameter | 0.634 IN |
| Stud/Lug Hole Diameter | 16.100 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 805890036036 |
CENTRIC 120.65071 Part Interchanges
| Brand | Part Number |
|---|---|
| Raybestos Brakes | 66823, 66823FZN, 66823PER, 66823R |
| Neotek Premium Drums and Rotors | 107196GF |
| N/A | BD125660, BD125660E, 153145258, E125-70-076, BR5407402, 54074, 54074G, F81A2C026C, F81Z2C026BB, F81Z2C026CA, 1C3Z1V125DA, YC3Z2C026BB, XC3Z2C026BB, BRR94, 1C3Z1V125F, 102002, 145258, 4886823, 86823, AR8571, E12570076, E12337, 120.65071, 54074GT, 54074DSR, 130773, YH145258, 1407-25409, 54074DSL, X51293, 27107, 19907, 8942071, 90054161, 18A934A |
CENTRIC 120.65071 Fits Vehicles
- Ford F-350 Super Duty (1999-2004)
- Ford F-250 Super Duty (1999-2004)
- Ford Excursion (2000-2005)
CENTRIC 120.65071 Cross References
We have 7 alternatives for the 120.65071 by CENTRIC:
