(888) 312-8812 Login SignupCENTRIC 120.65052 Centric Premium Brake Rotor
Tap to view 4 more
SHIPS TODAY
MSRP: $58.98
$4749
Save $11.49
Limited availability at this price!
In Stock
Get it by Tuesday, Jan 6
CENTRIC 120.65052 Part Description
Manufacturer
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
CENTRIC 120.65052 Specifications
Product Attributes
| Max Pb Drum Dia [cntrc] Mm | 185.000 |
| Misc Holes [cntrc] | 0 |
| Weight [cntrc] Lbs | 12.000 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Kgs | 5.450 |
| Disc Mounting [cntrc] | Floating / DIH |
| Max Pb Drum Dia [cntrc] In | 7.283 |
| Product Grade [cntrc] | Premium |
| Discard Thickness | 11.000 MM |
| Discard Thickness | 0.433 IN |
| Nominal Thickness | 11.900 MM |
| Nominal Thickness | 0.469 IN |
| Hat Finish | Coated |
| Overall Height | 2.299 IN |
| Overall Height | 58.400 MM |
| Outside Diameter | 285.000 MM |
| Outside Diameter | 11.220 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Solid |
| Nominal Drum Diameter | 184.000 MM |
| Nominal Drum Diameter | 7.244 IN |
| Bearings Included | No |
| Center Hole Diameter | 2.807 IN |
| Center Hole Diameter | 71.300 MM |
| Mounting Bolt Hole Circle Diameter | 4.500 IN |
| Mounting Bolt Hole Circle Diameter | 114.300 MM |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 14.500 MM |
| Stud/Lug Hole Diameter | 0.571 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| UPC | 805890043515 |
CENTRIC 120.65052 Part Interchanges
| Brand | Part Number |
|---|---|
| Raybestos Brakes | 66565, 66565FZN, 66565R |
| Neotek Premium Drums and Rotors | 107161GF |
| N/A | BD125463, E125-70-057, 6492190, 54032, 54032G, 107161, YL242C026AA, 4087729, F5TZ2C026A, F5TZ2C026A2, YL2Z1V125BA, YL2Z2C026BA, 3760664, 145052, 86565, 86597, 4886565, AR8552, E12570057, 54032HC, 120.65052, YL242C026A, 2539203, 54032DSR, 1407-25472, YH145052, 54032DSL, 27045, X51010, BR1994, DDF1378, 19767, 8942052, 90054142 |
CENTRIC 120.65052 Fits Vehicles
- Mercury Mountaineer (1997-2001)
- Ford Explorer Sport (2001-2002)
- Ford Ranger (1998-2002)
- Ford Explorer (1995-2001)
CENTRIC 120.65052 Cross References
We have 7 alternatives for the 120.65052 by CENTRIC:
