(888) 312-8812 Login SignupCENTRIC 120.65051 Centric Premium Brake Rotor
Tap to view 4 more
MSRP: $125.63
$8199
Save $43.64
Limited availability at this price!
In Stock
Get it by Friday, Jan 2
CENTRIC 120.65051 Part Description
Manufacturer
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
CENTRIC 120.65051 Specifications
Product Attributes
| Product Grade [cntrc] | Premium |
| Inner Seal # [cntrc] | 417.61003 |
| Outer Bearing # [cntrc] | 410.91002 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Lbs | 20.500 |
| Disc Mounting [cntrc] | Hub & Rotor |
| Inner Bearing # [cntrc] | 410.91005 |
| Vane Style [cntrc] | Straight |
| Weight [cntrc] Kgs | 9.320 |
| Misc Holes [cntrc] | 0 |
| Discard Thickness | 24.500 MM |
| Discard Thickness | 0.965 IN |
| Nominal Thickness | 26.100 MM |
| Stud/Lug Hole Quantity | 5 |
| Mounting Bolt Hole Circle Diameter | 4.500 IN |
| Mounting Bolt Hole Circle Diameter | 114.300 MM |
| Center Hole Diameter | 2.772 IN |
| Center Hole Diameter | 70.400 MM |
| Bearings Included | No |
| Bolt Thread Pitch | 20.000 IN |
| Solid Or Vented Type Rotor | Vented |
| Rotor Outside Diameter | 11.280 in |
| Rotor Outside Diameter | 286.500 MM |
| Surface Type | Smooth |
| ABS Tone Ring Included | Yes |
| Overall Height | 4.252 IN |
| Overall Height | 108.000 MM |
| Stud Thread Diameter | 0.500 IN |
| Hat Finish | Coated |
| Nominal Thickness | 1.028 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 805890043508 |
CENTRIC 120.65051 Part Interchanges
| Brand | Part Number |
|---|---|
| Raybestos Brakes | 66597, 66597FZN, 66597R, 680093, 680093R |
| Neotek Premium Drums and Rotors | 107135GF |
| N/A | BD126563, BD125495, BD125495E, BD125773, 0832761, E125-70-056, BR5402902, 6492200, 54029, 54104, 54029G, 54104G, 54123G, 54180G, 107135, AL5Z1102A, XL5Z1102FA, ZZP333251, ZZP333251A, 4L5Z1102BA, 3L5Z1102AA, F67A1102AA, F67Z1102GA, F5TZ1102H, F6TZ1102C, F87Z1102GA, 2U2Z1V102DA, BRR298, BRR204, 102573E, 145366, 145076, 86559, 86597, 4886597, 48880093, 880093, AR8551, E12570056, 54029HC, 54123HC, 120.65051, 4L5Z1102B, 616115, 210724, 210724C, K191B1102, F67AGA, 130250, YH145076, YH145366, 1407-25556, 27075, X51007, 680905, 19852, 19360, 942051, 60054141 |
CENTRIC 120.65051 Fits Vehicles
- Mercury Mountaineer (1997-2001)
- Ford Explorer (1995-2001)
- Ford Ranger (1998-2011)
- Mazda B4000 (1998-2009)
- Mazda B3000 (2001-2004, 2006-2008)
- Mazda B2500 (2001)
- Mazda B2300 (2001-2002)
CENTRIC 120.65051 Cross References
We have 12 alternatives for the 120.65051 by CENTRIC:
CENTRIC 120.65051 Customer Reviews
No reviews yet
Be the first to review this product!
