CENTRIC 120.65003 Part Description
Manufacturer
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
CENTRIC 120.65003 Specifications
Product Attributes
| Vane Style [cntrc] | Straight |
| Inner Seal # [cntrc] | 417.65008 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Inner Bearing # [cntrc] | 415.68004 |
| Weight [cntrc] Lbs | 37.010 |
| Weight [cntrc] Kgs | 16.820 |
| Disc Mounting [cntrc] | Hub & Rotor |
| Misc Holes [cntrc] | 0 |
| Inner Race # [cntrc] | 416.68003 |
| Product Grade [cntrc] | Premium |
| Outer Bearing # [cntrc] | 415.68002 |
| Outer Race # [cntrc] | 416.68001 |
| Discard Thickness | 23.880 MM |
| Discard Thickness | 0.940 IN |
| Nominal Thickness | 25.400 MM |
| Nominal Thickness | 1.000 IN |
| Hat Finish | Coated |
| Stud Thread Diameter | 0.500 IN |
| Overall Height | 135.400 MM |
| Overall Height | 5.331 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Rotor Outside Diameter | 319.000 MM |
| Rotor Outside Diameter | 12.559 in |
| Solid Or Vented Type Rotor | Vented |
| Bolt Thread Pitch | 20.000 IN |
| Bearings Included | No |
| Center Hole Diameter | 91.400 MM |
| Center Hole Diameter | 3.598 IN |
| Mounting Bolt Hole Circle Diameter | 165.100 MM |
| Mounting Bolt Hole Circle Diameter | 6.500 IN |
| Stud/Lug Hole Quantity | 8 |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 805890035916 |
CENTRIC 120.65003 Part Interchanges
| Brand | Part Number |
|---|---|
| Raybestos Brakes | 6044, 6044R |
| N/A | BD60450, E125-70-008, 5420, 210143, 210143C, 85600, 5420G, D5UZ1102C, D5UZ1105C, 120.65003, 78-85600, PRT1129, 141129, 102635, 4885600, 8942003, AR8503, E12570008 |
CENTRIC 120.65003 Fits Vehicles
- Ford E-200 Econoline (1973-1974)
- Ford F-250 (1973-1975)
- Ford E-250 Econoline Club Wagon (1975-1976)
- Ford E-250 Econoline (1975-1976)
CENTRIC 120.65003 Cross References
We have 4 alternatives for the 120.65003 by CENTRIC:
