Name: Centric 120.63062 Centric Premium Brake Rotor
SKU: 12063062
Price: 69.99 USD
Availability: InStock

Centric Premium Brake Rotor

Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life

Disc Mounting [cntrc]	Floating / DIH
Hat Id [cntrc] Mm	156.300
Weight [cntrc] Lbs	18.000
Vane Style [cntrc]	Straight
Hat Id [cntrc] In	6.154
California Proposition 65 Text [cntrc]	WARNING: Cancer and Reproductive Harm
Max Pb Drum Dia [cntrc] Mm	185.500
Product Grade [cntrc]	Premium
Misc Holes [cntrc]	0
Weight [cntrc] Kgs	8.180
Discard Thickness	0.807 IN
Discard Thickness	20.500 MM
Nominal Thickness	0.866 IN
Nominal Thickness	22.000 MM
Hat Finish	Coated
Overall Height	2.654 IN
Overall Height	67.400 MM
Outside Diameter	320.000 MM
Outside Diameter	12.598 IN
ABS Tone Ring Included	No
Surface Type	Smooth
Solid Or Vented Type Rotor	Vented
Nominal Drum Diameter	183.900 MM
Nominal Drum Diameter	7.240 IN
Bearings Included	No
Center Hole Diameter	2.858 IN
Center Hole Diameter	72.600 MM
Mounting Bolt Hole Circle Diameter	4.500 IN
Mounting Bolt Hole Circle Diameter	114.300 MM
Stud/Lug Hole Quantity	5
Stud/Lug Hole Diameter	0.657 IN
Stud/Lug Hole Diameter	16.700 MM

Harmonized Tariff Code (Schedule B)	8708300050
Harmonized Tariff Code (HTS)	8708305030
NAFTA Preference Criterion Code	B
Country of Origin (Primary)	CN
UPC	805890210481
