(888) 312-8812 Login SignupCENTRIC 120.63062 Centric Premium Brake Rotor
Tap to view 4 more
$11549
Limited availability at this price!
In Stock
Get it by Monday, Feb 23
CENTRIC 120.63062 Part Description
Manufacturer
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
- Painted hat and outer edge for corrosion resistance
- Symmetric vane; split-core castings for uniform heat distribution. Anti-corrosive paint protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life.
- Painted Hat and Outer Edge
- Optimal Surface Finish
- Optimal surface finish for consistent stopping feel from the first stop
- Advanced Metallurgy
- Advanced metallurgy for optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- OE vane design and plate thickness for heat capacity and strength
- Low Initial Lateral Run-Out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
- Precision Balance
- Precision balance for vibration free performance
CENTRIC 120.63062 Specifications
Product Attributes
| Disc Mounting [cntrc] | Floating / DIH |
| Hat Id [cntrc] Mm | 156.300 |
| Weight [cntrc] Lbs | 18.000 |
| Vane Style [cntrc] | Straight |
| Hat Id [cntrc] In | 6.154 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Max Pb Drum Dia [cntrc] Mm | 185.500 |
| Product Grade [cntrc] | Premium |
| Misc Holes [cntrc] | 0 |
| Weight [cntrc] Kgs | 8.180 |
| Discard Thickness | 0.807 IN |
| Discard Thickness | 20.500 MM |
| Nominal Thickness | 0.866 IN |
| Nominal Thickness | 22.000 MM |
| Hat Finish | Painted |
| Overall Height | 2.654 IN |
| Overall Height | 67.400 MM |
| Outside Diameter | 320.000 MM |
| Outside Diameter | 12.598 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Nominal Drum Diameter | 183.900 MM |
| Nominal Drum Diameter | 7.240 IN |
| Bearings Included | No |
| Center Hole Diameter | 2.858 IN |
| Center Hole Diameter | 72.600 MM |
| Mounting Bolt Hole Circle Diameter | 4.500 IN |
| Mounting Bolt Hole Circle Diameter | 114.300 MM |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 0.657 IN |
| Stud/Lug Hole Diameter | 16.700 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890210481 |
CENTRIC 120.63062 Cross References
| Brand | Part Number |
|---|---|
| 780257, BD126270 | |
| ADVICS | P6R365U |
| N/A | BD126270, BD126270E, E125-68-067, BR5302402, 53024, 53024G, 4779209AA, 4779209AB, 4779209AC, 4779209AD, 4779209AE, 4779209AF, 4779209AG, 2AMV9209AG, 68368071AA, 145568, 880257, E12568067, 120.63062, 53024GT, 0204262825, 02042K2426, 53024DSR, 53024DSL, 1407-26850, YH145568, 27355, DDF1766, 2053024, 90039018 |
| NEOTEK | 107080GF |
| Neotek Premium Drums and Rotors | 107080GF |
| PRONTO | BR5302402 |
| RAYBESTOS | 780257, 780257FZN, 780257R, 781049, 781049FZN, 781049R, 780257R2 |
| Raybestos Brakes | 780257, 780257FZN, 780257R, 781049, 781049FZN, 781049R |
| WAGNER | BD180300, BD126270E, BD126270 |
CENTRIC 120.63062 Fits Vehicles
- Dodge Magnum (2005-2008)
- Dodge Charger (2006-2022)
- Dodge Challenger (2009-2022)
- Chrysler 300 (2005-2021)
