(888) 312-8812 Login SignupCENTRIC 120.63057 Centric Premium Brake Rotor
Tap to view 4 more
MSRP: $94.51
$6449
Save $30.02
Limited availability at this price!
In Stock
Get it by Thursday, Feb 19
CENTRIC 120.63057 Part Description
Manufacturer
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
- Painted hat and outer edge for corrosion resistance
- Symmetric vane; split-core castings for uniform heat distribution. Anti-corrosive paint protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life.
- Painted Hat and Outer Edge
- Optimal Surface Finish
- Optimal surface finish for consistent stopping feel from the first stop
- Advanced Metallurgy
- Advanced metallurgy for optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- OE vane design and plate thickness for heat capacity and strength
- Low Initial Lateral Run-Out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
- Precision Balance
- Precision balance for vibration free performance
CENTRIC 120.63057 Specifications
Product Attributes
| Max Pb Drum Dia [cntrc] Mm | 184.700 |
| Misc Holes [cntrc] | 0 |
| Weight [cntrc] Lbs | 16.500 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Kgs | 7.500 |
| Disc Mounting [cntrc] | Floating / DIH |
| Max Pb Drum Dia [cntrc] In | 7.272 |
| Product Grade [cntrc] | Premium |
| Discard Thickness | 12.500 MM |
| Discard Thickness | 0.492 IN |
| Nominal Thickness | 14.000 MM |
| Nominal Thickness | 0.551 IN |
| Hat Finish | Painted |
| Overall Height | 59.000 MM |
| Overall Height | 2.323 IN |
| Outside Diameter | 312.000 MM |
| Outside Diameter | 12.283 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Solid |
| Nominal Drum Diameter | 183.600 MM |
| Nominal Drum Diameter | 7.228 IN |
| Bearings Included | No |
| Center Hole Diameter | 82.000 MM |
| Center Hole Diameter | 3.228 IN |
| Mounting Bolt Hole Circle Diameter | 127.000 MM |
| Mounting Bolt Hole Circle Diameter | 5.000 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 0.602 IN |
| Stud/Lug Hole Diameter | 15.300 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890194453 |
CENTRIC 120.63057 Cross References
CENTRIC 120.63057 Fits Vehicles
- Chrysler Pacifica (2004-2008)
