Centric 120.63056 - Centric Premium Brake Rotor
$11799
MSRP: $144.64
Save: $26.65
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
Product Attributes
| Disc Mounting [cntrc] | Floating |
| Weight [cntrc] Kgs | 11.140 |
| Vane Style [cntrc] | Pillar |
| Weight [cntrc] Lbs | 24.500 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Misc Holes [cntrc] | 0 |
| Product Grade [cntrc] | Premium |
| Discard Thickness | 1.181 IN |
| Discard Thickness | 30.000 MM |
| Nominal Thickness | 1.260 IN |
| Nominal Thickness | 32.000 MM |
| Hat Finish | Coated |
| Overall Height | 2.047 IN |
| Overall Height | 52.000 MM |
| Outside Diameter | 355.000 MM |
| Outside Diameter | 13.976 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 2.890 IN |
| Center Hole Diameter | 73.400 MM |
| Mounting Bolt Hole Circle Diameter | 114.300 MM |
| Mounting Bolt Hole Circle Diameter | 4.500 IN |
| Stud/Lug Hole Quantity | 6 |
| Stud/Lug Hole Diameter | 0.531 IN |
| Stud/Lug Hole Diameter | 13.500 MM |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| UPC | 805890136651 |
Part Interchanges
CENTRIC 120.63056 Cross Reference
We have 4 alternatives for the 120.63056 by CENTRIC:
Fits Vehicles
- SRT Viper (2013-2014)
- Dodge Viper (2003-2006, 2008-2010, 2015-2017)
