Centric 120.62062 - Centric Premium Brake Rotor
$5549
MSRP: $67.69
Save: $12.20
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
Product Attributes
| Disc Mounting [cntrc] | Floating / DIH |
| Max Pb Drum Dia [cntrc] Mm | 190.400 |
| Misc Holes [cntrc] | 0 |
| Weight [cntrc] Lbs | 14.200 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Kgs | 6.450 |
| Vane Style [cntrc] | Pillar |
| Max Pb Drum Dia [cntrc] In | 7.496 |
| Product Grade [cntrc] | Premium |
| Discard Thickness | 0.945 IN |
| Discard Thickness | 24.000 MM |
| Nominal Thickness | 1.020 IN |
| Nominal Thickness | 25.900 MM |
| Hat Finish | Coated |
| Overall Height | 48.400 MM |
| Overall Height | 1.906 IN |
| Outside Diameter | 305.000 MM |
| Outside Diameter | 12.008 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Nominal Drum Diameter | 190.100 MM |
| Nominal Drum Diameter | 7.484 IN |
| Bearings Included | No |
| Center Hole Diameter | 70.700 MM |
| Center Hole Diameter | 2.783 IN |
| Mounting Bolt Hole Circle Diameter | 4.748 IN |
| Mounting Bolt Hole Circle Diameter | 120.600 MM |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 13.500 MM |
| Stud/Lug Hole Diameter | 0.531 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| UPC | 805890035657 |
Part Interchanges
CENTRIC 120.62062 Cross Reference
We have 7 alternatives for the 120.62062 by CENTRIC:
Fits Vehicles
- Cadillac XLR (2004-2009)
- Chevrolet Corvette (1997-2013)
