CENTRIC 120.62046 Part Description
Manufacturer
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
CENTRIC 120.62046 Specifications
Product Attributes
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Misc Holes [cntrc] | 0 |
| Product Grade [cntrc] | Premium |
| Disc Mounting [cntrc] | Floating |
| Weight [cntrc] Kgs | 9.320 |
| Vane Style [cntrc] | Curved |
| Weight [cntrc] Lbs | 20.500 |
| Discard Thickness | 26.400 MM |
| Discard Thickness | 1.039 IN |
| Nominal Thickness | 28.000 MM |
| Nominal Thickness | 1.102 IN |
| Hat Finish | Coated |
| Overall Height | 55.900 MM |
| Overall Height | 2.201 IN |
| Outside Diameter | 330.000 MM |
| Outside Diameter | 12.992 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 70.600 MM |
| Center Hole Diameter | 2.780 IN |
| Mounting Bolt Hole Circle Diameter | 120.700 MM |
| Mounting Bolt Hole Circle Diameter | 4.752 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 13.100 MM |
| Stud/Lug Hole Diameter | 0.516 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 805890035565 |
CENTRIC 120.62046 Part Interchanges
| Brand | Part Number |
|---|---|
| Raybestos Brakes | 56494R |
| N/A | BD61853, 6493890, 64 93 890, 55009, 107245, 55009G, 10157919, 10052203, 10257631, 101091, 141897, 86494, 4886494, 1272, AR8246, D17706, 55009GT, BPC6494, 55009DSL, 27321, BR1917, 56494, 8936046, 90047023D, 177678 |
CENTRIC 120.62046 Fits Vehicles
- Chevrolet Corvette (1988-1996)
CENTRIC 120.62046 Cross References
We have 3 alternatives for the 120.62046 by CENTRIC:
