CENTRIC 120.61076 Part Description
Manufacturer
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
CENTRIC 120.61076 Specifications
Product Attributes
| Disc Mounting [cntrc] | Floating / DIH |
| Max Pb Drum Dia [cntrc] In | 9.055 |
| Product Grade [cntrc] | Premium |
| Max Pb Drum Dia [cntrc] Mm | 230.000 |
| Misc Holes [cntrc] | 0 |
| Weight [cntrc] Lbs | 19.500 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Kgs | 8.860 |
| Discard Thickness | 0.472 IN |
| Discard Thickness | 12.000 MM |
| Nominal Thickness | 0.547 IN |
| Nominal Thickness | 13.900 MM |
| Hat Finish | Coated |
| Overall Height | 2.217 IN |
| Overall Height | 56.300 MM |
| Outside Diameter | 333.800 MM |
| Outside Diameter | 13.142 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Solid |
| Nominal Drum Diameter | 228.400 MM |
| Nominal Drum Diameter | 8.992 IN |
| Bearings Included | No |
| Center Hole Diameter | 2.783 IN |
| Center Hole Diameter | 70.700 MM |
| Mounting Bolt Hole Circle Diameter | 114.300 MM |
| Mounting Bolt Hole Circle Diameter | 4.500 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 0.555 IN |
| Stud/Lug Hole Diameter | 14.100 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 805890136613 |
CENTRIC 120.61076 Part Interchanges
| Brand | Part Number |
|---|---|
| Raybestos Brakes | 680108, 680108R |
| Neotek Premium Drums and Rotors | 1071103GF |
| N/A | BD126009, E125-66-081, 3W132C026B, 0204262357, 1407-25842, 54102, 27299, 54102G, 3W1Z2C026BA, 4U2Z1V125AA, 145380, 880108, AR8167, 90055004, E12566081 |
CENTRIC 120.61076 Fits Vehicles
- Lincoln Town Car (2003-2011)
CENTRIC 120.61076 Cross References
We have 5 alternatives for the 120.61076 by CENTRIC:
