CENTRIC 120.51017 Part Description
Manufacturer
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
CENTRIC 120.51017 Specifications
Product Attributes
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Misc Holes [cntrc] | 2 |
| Product Grade [cntrc] | Premium |
| Disc Mounting [cntrc] | Floating |
| Weight [cntrc] Kgs | 5.000 |
| Vane Style [cntrc] | Straight |
| Weight [cntrc] Lbs | 11.000 |
| Discard Thickness | 17.000 MM |
| Discard Thickness | 0.669 IN |
| Nominal Thickness | 0.748 IN |
| Nominal Thickness | 19.000 MM |
| Hat Finish | Coated |
| Overall Height | 52.000 MM |
| Overall Height | 2.047 IN |
| Outside Diameter | 241.000 MM |
| Outside Diameter | 9.488 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 2.449 IN |
| Center Hole Diameter | 62.200 MM |
| Mounting Bolt Hole Circle Diameter | 3.937 IN |
| Mounting Bolt Hole Circle Diameter | 100.000 MM |
| Stud/Lug Hole Quantity | 4 |
| Stud/Lug Hole Diameter | 0.492 IN |
| Stud/Lug Hole Diameter | 12.500 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 805890196075 |
CENTRIC 120.51017 Part Interchanges
| Brand | Part Number |
|---|---|
| Raybestos Brakes | 980163FZN, 980163R |
| N/A | FR05052, BD126200, 31321, YH145498, 25913, 31321G, 5171225061, 980163, 145498, 880163, 48880163, BFR115610, DDF1632, 60003018 |
CENTRIC 120.51017 Fits Vehicles
- Dodge Verna (2004-2006)
- Hyundai Accent (2003-2005)
CENTRIC 120.51017 Cross References
We have 4 alternatives for the 120.51017 by CENTRIC:
