CENTRIC 120.50018 Part Description
Manufacturer
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
CENTRIC 120.50018 Specifications
Product Attributes
| Disc Mounting [cntrc] | Floating / DIH |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Misc Holes [cntrc] | 3 |
| Max Pb Drum Dia [cntrc] Mm | 191.000 |
| Max Pb Drum Dia [cntrc] In | 7.520 |
| Weight [cntrc] Kgs | 5.230 |
| Weight [cntrc] Lbs | 11.500 |
| Product Grade [cntrc] | Premium |
| Discard Thickness | 10.400 MM |
| Discard Thickness | 0.409 IN |
| Nominal Thickness | 12.000 MM |
| Nominal Thickness | 0.472 IN |
| Hat Finish | Coated |
| Overall Height | 69.900 MM |
| Overall Height | 2.752 IN |
| Outside Diameter | 302.000 MM |
| Outside Diameter | 11.890 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Solid |
| Nominal Drum Diameter | 190.000 MM |
| Nominal Drum Diameter | 7.480 IN |
| Bearings Included | No |
| Center Hole Diameter | 3.780 IN |
| Center Hole Diameter | 96.000 MM |
| Mounting Bolt Hole Circle Diameter | 5.512 IN |
| Mounting Bolt Hole Circle Diameter | 140.000 MM |
| Stud/Lug Hole Quantity | 6 |
| Stud/Lug Hole Diameter | 12.300 MM |
| Stud/Lug Hole Diameter | 0.484 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 805890299028 |
CENTRIC 120.50018 Cross References
| Brand | Part Number |
|---|---|
| 980463, BD126441 | |
| ADVICS | R6R288U |
| N/A | 0833031, BD126441, E125-55-023, BR90029002, 44602, YH200503, 44602G, 584114D500, 584114D600, 31430, 880463, 2031430, 90021024, E12555023 |
| NEOTEK | 106948GF |
| Neotek Premium Drums and Rotors | 106948GF |
| PRONTO | BR90029002 |
| RAYBESTOS | 980463, 980463FZN, 980463R, 980463R2 |
| Raybestos Brakes | 980463, 980463FZN, 980463R |
| WAGNER | BD126441, BD126441E |
CENTRIC 120.50018 Fits Vehicles
- Kia Sedona (2006-2012, 2014)
- Hyundai Entourage (2007-2009)
