Centric 120.47017 - Centric Premium Brake Rotor

Part Number
120.47017
Manufacturer
CENTRIC
Description

Centric Premium Brake Rotor

details

$54.49

MSRP: $66.27

Save: $11.78

In stock

limited availability at this price!

New! No hassle Return Policy details
Free Economy shipping on orders over $299 details
Orders placed over the weekend will ship the following business day
Get it by Thursday, Feb 27
Pay over 3-12 months with Affirm Logo. Learn more
Minus Plus

CENTRIC part description

Product Description

Centric Premium Brake Rotor

Features & Benefits

  • Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life

Product Attributes

California Proposition 65 Text [cntrc] WARNING: Cancer and Reproductive Harm
Max Pb Drum Dia [cntrc] Mm 171.000
Weight [cntrc] Kgs 5.000
Disc Mounting [cntrc] Floating / DIH
Misc Holes [cntrc] 2
Max Pb Drum Dia [cntrc] In 6.732
Weight [cntrc] Lbs 11.000
Product Grade [cntrc] Premium
Discard Thickness 8.500 MM
Discard Thickness 0.335 IN
Nominal Thickness 0.394 IN
Nominal Thickness 10.000 MM
Hat Finish Coated
Overall Height 2.591 IN
Overall Height 65.800 MM
Outside Diameter 289.700 MM
Outside Diameter 11.406 IN
ABS Tone Ring Included No
Surface Type Smooth
Solid Or Vented Type Rotor Solid
Nominal Drum Diameter 170.000 MM
Nominal Drum Diameter 6.693 IN
Bearings Included No
Center Hole Diameter 58.000 MM
Center Hole Diameter 2.283 IN
Mounting Bolt Hole Circle Diameter 3.937 IN
Mounting Bolt Hole Circle Diameter 100.000 MM
Stud/Lug Hole Quantity 5
Stud/Lug Hole Diameter 0.508 IN
Stud/Lug Hole Diameter 12.900 MM

Additional Information

Harmonized Tariff Code (Schedule B) 8708300050
Harmonized Tariff Code (HTS) 8708305030
NAFTA Preference Criterion Code B
Country of Origin (Primary) CN
UPC 805890166344

Part Interchanges

CENTRIC 120.47017 Cross Reference

We have 8 alternatives for the 120.47017 by CENTRIC:

Fits Vehicles

  • Subaru Outback (2000-2004)
  • Subaru Legacy (2000-2004)
  • Subaru Baja (2003-2006)
