(888) 312-8812 Login SignupCENTRIC 120.45066 Centric Premium Brake Rotor
Tap to view 4 more
MSRP: $55.34
$3799
Save $17.35
Limited availability at this price!
In Stock
Get it by Thursday, Jan 8
CENTRIC 120.45066 Part Description
Manufacturer
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
CENTRIC 120.45066 Specifications
Product Attributes
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Kgs | 3.860 |
| Disc Mounting [cntrc] | Floating |
| Hat Id [cntrc] In | 5.945 |
| Product Grade [cntrc] | Premium |
| Hat Id [cntrc] Mm | 151.000 |
| Misc Holes [cntrc] | 0 |
| Weight [cntrc] Lbs | 8.500 |
| Discard Thickness | 0.354 IN |
| Discard Thickness | 9.000 MM |
| Nominal Thickness | 0.433 IN |
| Nominal Thickness | 11.000 MM |
| Hat Finish | Coated |
| Overall Height | 41.000 MM |
| Overall Height | 1.614 IN |
| Outside Diameter | 265.000 MM |
| Outside Diameter | 10.433 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Solid |
| Bearings Included | No |
| Center Hole Diameter | 2.827 IN |
| Center Hole Diameter | 71.800 MM |
| Mounting Bolt Hole Circle Diameter | 4.500 IN |
| Mounting Bolt Hole Circle Diameter | 114.300 MM |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 13.000 MM |
| Stud/Lug Hole Diameter | 0.512 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 805890322023 |
CENTRIC 120.45066 Part Interchanges
| Brand | Part Number |
|---|---|
| Raybestos Brakes | 980285, 980285FZN, 980285R |
| Neotek Premium Drums and Rotors | 106634GF |
| N/A | 120.45066, BD126386, BD126386E, YH145619, 1407-77172, 31365, 25873, 08A02910, 31365G, BP4Y26215E, BP4Y26251B, BP4Y26251C, BP4Y26251D, C24Y26251B, C24Y26251C, C24Y26251D, BFF426251, 981059, 880285, DDF1420, 2031365, DF4419, 90080039 |
CENTRIC 120.45066 Fits Vehicles
- Mazda 3 Sport (2009-2010, 2012-2013)
- Mazda 3 (2004-2013)
CENTRIC 120.45066 Cross References
We have 6 alternatives for the 120.45066 by CENTRIC:
