(888) 312-8812 Login SignupWABCO 4324210380 AD-SysS 1800UP Single Cartridge Air Brake Dryer with Coalescing Filter, Replaces 4324210520
Tap to view 2 more
$98599
90 Day Lead Time
Due to limited availability, we will confirm your order and notify you within 1 business day.
WABCO 4324210380 Part Description
Manufacturer
Features & Benefits
- Replaces the older 4324210520 model with upgraded filtration technology
- Integrated coalescing filter traps oil mist to protect air valves
- Combines desiccant and oil separation in a single cartridge
- Prevents sludge buildup that causes air system failure
WABCO Air Brake Dryer
The WABCO Air Brake Dryer provides a comprehensive solution for removing contaminants from heavy-duty air systems. Unlike standard dryers that only address moisture, this unit features a specialized coalescing stage that strips out the oil aerosols often pumped into the lines by aging compressors. This specific WABCO 4324210380 air brake dryer assembly serves as a direct upgrade for the 4324210520 model, fitting into the existing mounting location without requiring plumbing changes. Its efficient single-cartridge design combines the desiccant bed and oil separator into one element, simplifying future maintenance tasks for fleet mechanics. By keeping the air tanks clean and dry, it prevents the formation of sludge that leads to frozen valves and brake system malfunctions.
WABCO 4324210380 Specifications
Product Attributes
| Port thread 21 | 1/2" - 14 NPTF |
| Opening Pressure | 11.0 Bar |
| Voltage | 12 V |
| Heating Connection | 280 Metri-Pack Nr. 1202 0599 |
| Cut-Out Pressure | 7.9 to 9.0 Bar |
| Cartridge Type | Desiccant Cartridge |
| Port Thread 4/23 | 1/4" - 18 NPTF |
| Temperature Range | -40°C to +80°C |
| Weight | 11.1113 |
| Exhaust | JED-463-0 |
| Max. operating pressure | 9.0 Bar |
| Port thread 22 | 1/4" - 18 NPTF |
| Part Type | Premium Original Quality |
| Product Category | Device |
| Technical specification | OE Specification |
WABCO 4324210380 Cross References
| Brand | Part Number |
|---|---|
| MACK | 8235-S4324210520X, 6300-432421038R |
| VOLVO | WAB432421038R |
| WABCO | 4324210520 |
WABCO 4324210380 Customer Reviews
No reviews yet
Be the first to review this product!
WABCO 4324210380 Manufacturer Information
Whether it’s for cars, buses, trucks, or trailers, WABCO® is at the frontline at developing and providing products and systems to make vehicles safer and easier to control. Founded in 1869, WABCO is a major supplier of braking, stability, suspension and transmissions in the Americas and beyond. The company is recognized as introducing the modern air brake system in 1869, and continues to lead the industry in air brake design and production for the heavy duty and commercial vehicle sectors. Today, WABCO operates as a division of the German auto parts maker ZF and employs 16,000 employees in facilities in 36 countries worldwide.
