(888) 312-8812 Login SignupDELPHI TC7960 Control Arm and Ball Joint Assembly
Tap to view 13 more
$12199
Limited availability at this price!
In Stock
Get it by Monday, Dec 22
DELPHI TC7960 Part Description
DELPHI TC7960 Specifications
Product Attributes
| Item Grade | Standard Replacement |
| Position(s) | Front Left Lower |
| Pre-Greased | Yes |
| Grease Fitting Included | No |
| Bushings Included | Yes |
| Ball Joint Mounting Type | Press In |
| Ball Joint Stud Type | Threaded |
| Control Arm Construction | Stamped |
| Control Arm Material | Steel |
| Mounting Hardware Included | Yes |
| Adjustable | No |
| Greaseable | No |
| Control Arm Maximum Width | 100.00 MM |
| Control Arm Color | Black |
| Ball Joint Stud Length | 3.157 IN |
| Ball Joint Stud Length | 80.20 MM |
| Control Arm Maximum Length | 16.417 IN |
| Control Arm Maximum Length | 417.00 MM |
| Mounting Hole Diameter | 0.610 IN |
| Mounting Hole Diameter | 15.50 MM |
| Bushing Material | Rubber |
| Thread Direction | Clockwise (Right) |
| Bushing Color | Black |
| Finish | Painted |
| Dust Boot Included | Yes |
| Ball Joint Included | Yes |
| Grade Type | Premium |
| Boot Material | Chloroprene Rubber (CR) |
| Locking Nut Included | Yes |
| Boot Color | Black |
| Steering Type | Power |
| Bearing Material | Plastic |
| Dust Boot Material | Chloroprene Rubber (CR) |
| Control Arm Maximum Width | 3.937 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708807000 |
| Harmonized Tariff Code (HTS) | 8708806590 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Country of Origin (Primary) | TR |
| UPC | 00689604367803 |
| VMRS Code | 016001001 |
| UNSPSC | 25172013 |
DELPHI TC7960 Part Interchanges
| Brand | Part Number |
|---|---|
| Subaru | 20202 SA010 |
| MAS Industries | CB72003 |
| Dorman | 526-809 |
| N/A | CMS801039, GS801039 |
DELPHI TC7960 Fits Vehicles
- Subaru Forester (2003-2005)
