Name: Goodyear Belts 22570 Accessory Drive Belt - V-Belt, 57 in. Effective Length, EPDM
SKU: 22570
Price: 28.49 USD
Availability: InStock

GOODYEAR BELTS part description

Product Description

V-Belt

Features & Benefits

Meets or Exceeds OEM Specifications
EPDM Rubber Compound known for its excellent resistance to heat, ozone, weathering, and abrasion, ensuring long-lasting durability in automotive applications.
Long-life EPDM Rubber Compound
Radial Cogged design reduces bending resistance and improves power transmission efficiency, leading to enhanced performance and longevity, ensuring the longevity of automotive engine systems.
Radial Cog design to eliminate stress risers that can cause cracking
Polyester Cord Reinforcement, providing superior tensile strength and resistance to stretching, ensuring reliable power transmission and reduced maintenance.
Proprietary rubber formulation for quiet operation
Precision ground sides helps reduce noise and vibration in automotive engine systems, enhancing overall driving comfort and smoothness.
Precision ground sides for maximum pulley contact
Temperature Resistance, suitable for automotive applications, these belts maintain their performance even in extreme operating conditions.
High strength tensile cords designed for minimal tension decay and low maintenance
Limited Lifetime Warranty

Product Attributes

V-belt Profile	15A
Top Width (mm)	17 MM
Top Width (in)	0.669 IN
Thickness (mm)	10.5 mm
Thickness (in)	0.413 In
Rib Angle	36⁰ DD
Profile Series	22
Outside Circumference	1462 mm
Outside Circumference	57.57 in
Effective Length	1448 mm
Effective Length	57 in
Cord Material	Polyester
Item Weight (lbs)	0.57 LB
Item Weight (kg)	0.26 KG
Belt Material	EPDM
Angle	36 DD
Color	Black
Construction	Cogged
Cross Section Designation	15A
Grade Type	OE Performance
9837	Yes
Profile Type	22
Sae Standard	J636
9453	J637
Strand Quantity	1
Thickness	0.413 IN
Thickness	10.5 MM
Top Cogged	No
Top Width	0.669 in
Top Width	17 mm
Type	Automotive V-Belt

Additional Information

Stock Status	S
Warranty Time	1
Warranty Special	1 Year Limited Warranty
Warranty Time UOM	YR
Warranty Special UOM	TX
Country of Origin (Primary)	IN
Harmonized Tariff Code (HTS)	4010390000
Harmonized Tariff Code (Schedule B)	4010390000
Canadian Harmonizing Tariff Code	4010390000
UPC	00195199101574
VMRS Code	065005003
UNSPSC	26111801

Part Interchanges

GOODYEAR BELTS 22570 Cross Reference

We have 50 alternatives for the 22570 by GOODYEAR BELTS:

Fits Vehicles

Mack RWS (1981-1982)
Mack RWL (1981)
Peterbilt 372 (1989-1991)
Peterbilt 362 (1983-1991)
Kenworth W900 (1981-2003)
Kenworth T800 (1987-1996)
Kenworth T600A (1986-1999)
Kenworth T2000 (1997-1999)
International 9800 SBA (1997)
International 9400 (1990-1995)
International 9700 (1989, 1996)
International 9600 (1989, 1996)
International 9300 (1989-1995)
Suzuki Aerio (2002)
White WIS (1984)
White WIL (1984-1988)
White/GMC WIL (1988-1992)
White WCL (1983-1988)
White/GMC WIM (1988-1994)
White WIM (1984-1988)
White WCS (1981-1988)
White WCM (1981-1988)
White WIA (1988)
White/GMC WCM (1988-1994)
White/GMC WCL (1988-1992)
White/GMC WIA (1988-1995)
GMC Astro (1981-1983)
