CENTRIC part description

Product Description

Centric GCX Rotor with Full Coating

Product Attributes

Hat Id [cntrc] In 8.870
Disc Mounting [cntrc] Floating / DIH
Misc Holes [cntrc] 2
Vane Style [cntrc] Straight
Weight [cntrc] Kgs 16.900
Hat Id [cntrc] Mm 225.310
Weight [cntrc] Lbs 37.250
California Proposition 65 Text [cntrc] WARNING: Cancer and Reproductive Harm
Product Grade [cntrc] Premium
Discard Thickness 32.500 MM
Discard Thickness 1.280 IN
Nominal Thickness 34.100 MM
Nominal Thickness 1.343 IN
Disc Finish Fully Coated
Hat Finish Coated
Overall Height 119.200 MM
Overall Height 4.693 IN
Outside Diameter 14.173 IN
Outside Diameter 360.000 MM
ABS Tone Ring Included No
Surface Type Smooth
Solid Or Vented Type Rotor Vented
Nominal Drum Diameter 226.240 MM
Nominal Drum Diameter 8.907 IN
Bearings Included No
Center Hole Diameter 127.000 MM
Center Hole Diameter 5.000 IN
Mounting Bolt Hole Circle Diameter 180.000 MM
Mounting Bolt Hole Circle Diameter 7.087 IN
Stud/Lug Hole Quantity 8
Stud/Lug Hole Diameter 16.200 MM
Stud/Lug Hole Diameter 0.638 IN

Fits Vehicles

  • Chevrolet Silverado 3500 (2015-2018)
  • Chevrolet Silverado 2500 (2014-2018)
  • GMC Sierra 3500 HD (2011-2024)
  • GMC Sierra 2500 HD (2011-2024)
  • Chevrolet Silverado 3500 HD (2011-2024)
  • Chevrolet Silverado 2500 HD (2011-2024)
  • Chevrolet Suburban 3500 HD (2016-2019)
