CENTRIC part description

Product Description

Centric GCX Rotor with Full Coating

Product Attributes

Disc Mounting [cntrc] Hub & Rotor
Vane Style [cntrc] Straight
California Proposition 65 Text [cntrc] WARNING: Cancer and Reproductive Harm
Misc Holes [cntrc] 0
Inner Seal # [cntrc] 417.66000
Inner Bearing # [cntrc] 410.91005
Outer Bearing # [cntrc] 410.91003
Weight [cntrc] Kgs 13.360
Weight [cntrc] Lbs 29.400
Product Grade [cntrc] Premium
Discard Thickness 30.860 MM
Discard Thickness 1.215 IN
Nominal Thickness 32.590 MM
Nominal Thickness 1.283 IN
Disc Finish Fully Coated
Hat Finish Coated
Stud Thread Diameter 0.500 IN
Overall Height 124.000 MM
Overall Height 4.882 IN
ABS Tone Ring Included No
Surface Type Smooth
54 301.000 MM
Rotor Outside Diameter 11.850 in
Solid Or Vented Type Rotor Vented
Bolt Thread Pitch 20.000 IN
Bearings Included No
Center Hole Diameter 77.700 MM
Center Hole Diameter 3.059 IN
Mounting Bolt Hole Circle Diameter 127.000 MM
Mounting Bolt Hole Circle Diameter 5.000 IN
Stud/Lug Hole Quantity 5

Fits Vehicles

  • Chevrolet R1500 Suburban (1989-1991)
  • Chevrolet R10 Suburban (1987-1988)
  • Chevrolet R10 (1987)
  • Chevrolet P10 (1975-1980)
  • Chevrolet C20 (1987)
  • Chevrolet G20 (1975-1995)
  • Chevrolet G10 (1975-1995)
  • Chevrolet C10 (1975-1986)
  • Chevrolet K5 Blazer (1975-1982)
  • Cadillac Brougham (1990-1992)
  • Pontiac Grandville (1971-1975)
  • Pontiac Catalina (1971-1976)
  • Pontiac Bonneville (1971-1976)
  • Oldsmobile Delta 88 (1971-1976)
  • Oldsmobile Custom Cruiser (1971-1976)
  • Oldsmobile 98 (1971-1976)
  • GMC P15/P1500 Van (1971-1974)
  • GMC G25/G2500 Van (1971-1974)
  • GMC G15/G1500 Van (1974)
  • GMC C15/C1500 Suburban (1971-1974)
  • GMC R1500 Suburban (1987-1991)
  • GMC R1500 (1987)
  • GMC P1500 (1979-1980)
  • GMC P15 (1975-1978)
  • Chevrolet Caprice (1971-1976)
  • Chevrolet C10 Suburban (1969-1986)
  • Chevrolet C10 Pickup (1969-1974)
  • Chevrolet Brookwood (1971-1972)
  • Chevrolet Blazer (1974)
  • Chevrolet Biscayne (1971-1972)
  • Chevrolet Bel Air (1971-1975)
  • Cadillac Fleetwood (1972-1976, 1981-1985)
  • Cadillac DeVille (1972-1976)
  • Cadillac Calais (1972-1976)
  • Buick Riviera (1971-1976)
  • Buick LeSabre (1971-1976)
  • Buick Estate Wagon (1971-1976)
  • Buick Electra (1971-1976)
  • Buick Centurion (1971-1973)
  • GMC G2500 (1979-1995)
  • GMC G25 (1975-1978)
  • GMC G1500 (1979-1995)
  • GMC G15 (1975-1978)
  • Pontiac Grand Safari (1971-1976)
  • GMC C1500 Suburban (1979-1986)
  • GMC C15 Suburban (1975-1978)
  • GMC C1500 (1979-1986)
  • GMC C15 (1975-1978)
  • Chevrolet C15 (1982-1986)
  • Cadillac Commercial Chassis (1973-1989, 1992)
  • Checker Taxicab (1971-1974)
  • GMC C15/C1500 Pickup (1971-1974)
  • Chevrolet Townsman (1971-1972)
  • Chevrolet P10 Van (1971-1974)
  • Chevrolet Kingswood (1971-1972)
  • Chevrolet Impala (1971-1976)
  • Chevrolet G20 Van (1971-1974)
  • Chevrolet G10 Van (1974)
  • GMC Jimmy (1975-1982)
  • Checker Marathon (1971-1982)
