Centric 320.62137F - Centric GCX Rotor with Full Coating
$9999
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
Centric GCX Rotor with Full Coating
Product Attributes
| Max Pb Drum Dia [cntrc] In | 8.602 |
| Product Grade [cntrc] | Premium |
| Max Pb Drum Dia [cntrc] Mm | 218.500 |
| Weight [cntrc] Kgs | 10.200 |
| Hat Id [cntrc] Mm | 214.600 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Hat Id [cntrc] In | 8.449 |
| Disc Mounting [cntrc] | Floating / DIH |
| Misc Holes [cntrc] | 1 |
| Weight [cntrc] Lbs | 22.450 |
| Discard Thickness | 19.500 MM |
| Discard Thickness | 0.768 IN |
| Nominal Thickness | 21.000 MM |
| Stud/Lug Hole Diameter | 0.630 IN |
| Stud/Lug Hole Diameter | 16.000 MM |
| Stud/Lug Hole Quantity | 6 |
| Mounting Bolt Hole Circle Diameter | 5.504 IN |
| Mounting Bolt Hole Circle Diameter | 139.800 MM |
| Center Hole Diameter | 3.094 IN |
| Center Hole Diameter | 78.600 MM |
| Bearings Included | No |
| Nominal Drum Diameter | 217.900 MM |
| Nominal Drum Diameter | 8.579 IN |
| Solid Or Vented Type Rotor | Vented |
| Surface Type | Smooth |
| ABS Tone Ring Included | No |
| Outside Diameter | 13.780 IN |
| Outside Diameter | 350.000 MM |
| Overall Height | 2.421 IN |
| Overall Height | 61.500 MM |
| Hat Finish | Coated |
| Disc Finish | Fully Coated |
| Nominal Thickness | 0.827 IN |
Fits Vehicles
- Cadillac XTS (2013-2019)
