Centric 320.62012F - Centric GCX Rotor with Full Coating
$9149
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
Centric GCX Rotor with Full Coating
Product Attributes
| Product Grade [cntrc] | Premium |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Inner Bearing # [cntrc] | 410.91006 |
| Inner Seal # [cntrc] | 417.62000 |
| Weight [cntrc] Kgs | 11.820 |
| Misc Holes [cntrc] | 0 |
| Vane Style [cntrc] | Straight |
| Disc Mounting [cntrc] | Hub & Rotor |
| Weight [cntrc] Lbs | 26.000 |
| Outer Bearing # [cntrc] | 410.91003 |
| Discard Thickness | 24.500 MM |
| Discard Thickness | 0.965 IN |
| Nominal Thickness | 26.300 MM |
| Nominal Thickness | 1.035 IN |
| Disc Finish | Fully Coated |
| Hat Finish | Coated |
| Stud Thread Diameter | 0.438 IN |
| Overall Height | 117.600 MM |
| Overall Height | 4.630 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| 54 | 301.200 MM |
| Rotor Outside Diameter | 11.858 in |
| Solid Or Vented Type Rotor | Vented |
| Bolt Thread Pitch | 20.000 IN |
| Bearings Included | No |
| Center Hole Diameter | 81.300 MM |
| Center Hole Diameter | 3.201 IN |
| Mounting Bolt Hole Circle Diameter | 127.000 MM |
| Mounting Bolt Hole Circle Diameter | 5.000 IN |
| Stud/Lug Hole Quantity | 5 |
Fits Vehicles
- Chevrolet R10 (1987)
- Pontiac Safari (1987-1989)
- Pontiac Parisienne (1983-1986)
- Chevrolet Impala (1978-1985)
- Pontiac Catalina (1978-1981)
- Pontiac Bonneville (1978-1981)
- Chevrolet Caprice (1978-1990)
- Oldsmobile Delta 88 (1978-1985)
- Oldsmobile Custom Cruiser (1978-1990)
- Chevrolet C10 (1981-1986)
- Oldsmobile 98 (1978-1984)
- Chevrolet Astro (1985-1993)
- Cadillac Seville (1978-1979)
- Cadillac Brougham (1987-1989)
- Cadillac Fleetwood (1978-1986)
- Cadillac DeVille (1978-1984)
- GMC Safari (1985-1993)
- Cadillac Commercial Chassis (1981-1985)
- Buick Riviera (1978)
- GMC R1500 (1987)
- Buick LeSabre (1977-1989)
- Buick Estate Wagon (1978-1983)
- Buick Electra (1978-1989)
- GMC C1500 (1981-1986)
- Chevrolet C15 (1982-1986)
