Centric 320.47031F - Centric GCX Rotor with Full Coating
$6549
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
Centric GCX Rotor with Full Coating
Product Attributes
| Vane Style [cntrc] | Straight |
| Weight [cntrc] Kgs | 6.360 |
| Misc Holes [cntrc] | 3 |
| Weight [cntrc] Lbs | 14.000 |
| Product Grade [cntrc] | Premium |
| Max Pb Drum Dia [cntrc] In | 7.520 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Max Pb Drum Dia [cntrc] Mm | 191.000 |
| Disc Mounting [cntrc] | Floating / DIH |
| Discard Thickness | 0.630 IN |
| Discard Thickness | 16.000 MM |
| Nominal Thickness | 18.000 MM |
| Nominal Thickness | 0.709 IN |
| Disc Finish | Fully Coated |
| Hat Finish | Coated |
| Overall Height | 63.500 MM |
| Overall Height | 2.500 IN |
| Outside Diameter | 289.800 MM |
| Outside Diameter | 11.409 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Nominal Drum Diameter | 190.000 MM |
| Nominal Drum Diameter | 7.480 IN |
| Bearings Included | No |
| Center Hole Diameter | 2.283 IN |
| Center Hole Diameter | 58.000 MM |
| Mounting Bolt Hole Circle Diameter | 100.000 MM |
| Mounting Bolt Hole Circle Diameter | 3.937 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 12.800 MM |
| Stud/Lug Hole Diameter | 0.504 IN |
Fits Vehicles
- Toyota 86 (2017-2020)
- Scion FR-S (2013-2016)
- Subaru Outback (2010-2014)
- Subaru Legacy (2010-2014)
- Subaru BRZ (2013-2020, 2022-2023)
