Centric 320.40083F - Centric GCX Rotor with Full Coating
$7399
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
Centric GCX Rotor with Full Coating
Product Attributes
| Weight [cntrc] Lbs | 14.650 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Max Pb Drum Dia [cntrc] Mm | 211.000 |
| Product Grade [cntrc] | Premium |
| Hat Id [cntrc] Mm | 176.300 |
| Hat Id [cntrc] In | 6.941 |
| Max Pb Drum Dia [cntrc] In | 8.307 |
| Disc Mounting [cntrc] | Floating / DIH |
| Weight [cntrc] Kgs | 6.640 |
| Misc Holes [cntrc] | 4 |
| Discard Thickness | 0.354 IN |
| Discard Thickness | 9.000 MM |
| Nominal Thickness | 11.000 MM |
| Nominal Thickness | 0.433 IN |
| Disc Finish | Fully Coated |
| Hat Finish | Coated |
| Overall Height | 63.300 MM |
| Overall Height | 2.492 IN |
| Outside Diameter | 299.800 MM |
| Outside Diameter | 11.803 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Solid |
| Nominal Drum Diameter | 8.260 IN |
| Nominal Drum Diameter | 209.800 MM |
| Bearings Included | No |
| Center Hole Diameter | 64.100 MM |
| Center Hole Diameter | 2.524 IN |
| Mounting Bolt Hole Circle Diameter | 114.200 MM |
| Mounting Bolt Hole Circle Diameter | 4.496 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 12.600 MM |
| Stud/Lug Hole Diameter | 0.496 IN |
Fits Vehicles
- Acura MDX (2014-2016)
