(888) 312-8812 Login SignupCENTRIC 320.40074F Centric GCX Rotor with Full Coating
$7499
Limited availability at this price!
In Stock
Get it by Tuesday, Jan 27
CENTRIC 320.40074F Part Description
CENTRIC 320.40074F Specifications
Product Attributes
| Max Pb Drum Dia [cntrc] Mm | 191.000 |
| Disc Mounting [cntrc] | Floating / DIH |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Max Pb Drum Dia [cntrc] In | 7.520 |
| Weight [cntrc] Lbs | 15.150 |
| Misc Holes [cntrc] | 5 |
| Product Grade [cntrc] | Premium |
| Weight [cntrc] Kgs | 6.890 |
| Discard Thickness | 9.000 MM |
| Discard Thickness | 0.354 IN |
| Nominal Thickness | 0.433 IN |
| Nominal Thickness | 11.000 MM |
| Disc Finish | Fully Coated |
| Hat Finish | Coated |
| Overall Height | 60.500 MM |
| Overall Height | 2.382 IN |
| Outside Diameter | 334.000 MM |
| Outside Diameter | 13.150 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Solid |
| Nominal Drum Diameter | 7.480 IN |
| Nominal Drum Diameter | 190.000 MM |
| Bearings Included | No |
| Center Hole Diameter | 70.100 MM |
| Center Hole Diameter | 2.760 IN |
| Mounting Bolt Hole Circle Diameter | 120.000 MM |
| Mounting Bolt Hole Circle Diameter | 4.724 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 14.700 MM |
| Stud/Lug Hole Diameter | 0.579 IN |
CENTRIC 320.40074F Cross References
| Brand | Part Number |
|---|---|
| MAGMA PRODUCTS | PSR263064 |
CENTRIC 320.40074F Fits Vehicles
- Acura TL (2009-2014)
