Centric 320.33039F - Centric GCX Rotor with Full Coating
$5699
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
Centric GCX Rotor with Full Coating
Product Attributes
| Weight [cntrc] Lbs | 17.500 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Misc Holes [cntrc] | 0 |
| Notes [cntrc] | Vented Hat |
| Product Grade [cntrc] | Premium |
| Weight [cntrc] Kgs | 7.950 |
| Disc Mounting [cntrc] | Floating |
| Vane Style [cntrc] | Straight |
| Discard Thickness | 0.906 IN |
| Discard Thickness | 23.000 MM |
| Nominal Thickness | 25.000 MM |
| Nominal Thickness | 0.980 IN |
| Disc Finish | Fully Coated |
| Hat Finish | Coated |
| Overall Height | 46.400 MM |
| Overall Height | 1.827 IN |
| Outside Diameter | 11.339 IN |
| Outside Diameter | 288.000 MM |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 2.677 IN |
| Center Hole Diameter | 68.000 MM |
| Mounting Bolt Hole Circle Diameter | 112.000 MM |
| Mounting Bolt Hole Circle Diameter | 4.409 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 15.500 MM |
| Stud/Lug Hole Diameter | 0.610 IN |
Fits Vehicles
- Audi A4 Quattro (1996-2004)
- Audi A6 Quattro (1995-2001)
- Audi A6 (1995-2001)
- Audi 100 Quattro (1992-1994)
- Audi 100 (1992-1994)
- Audi A4 (1996-2008)
- Volkswagen Passat (1998-2005)
