*Representative image - actual part not displayed
$7799
Limited availability at this price!
In Stock
Get it by Monday, Feb 16
CENTRIC 125.39061 Part Description
Manufacturer
Product Description
Centric Premium High Carbon Alloy Brake Rotor
Application Summary
Volvo XC40 2022-2019
Features & Benefits
- Centric Premium Rotor with advanced metallurgy that greatly reduces pad squeal. Especially effective with higher friction; European style brake pad compounds. Added Molybdenum and Chromium to resist rotor cracking
- Painted hat and outer edge for corrosion resistance
- Painted Hat and Outer Edge
- Optimal Surface Finish
- Optimal surface finish for consistent stopping feel from the first stop
- Advanced Metallurgy
- Advanced metallurgy for optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- OE vane design and plate thickness for heat capacity and strength
- Low Initial Lateral Run-Out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
- Precision Balance
- Precision balance for vibration free performance
High Carbon Alloy; Centric Parts; CentricParts; Centric Brake Rotors CentricParts Break Rotor; StopTech; Stop Tech; StopTech Hig Carbon Rotor
CENTRIC 125.39061 Specifications
Product Attributes
| Discard Thickness | 25.0 MM |
| Nominal Thickness | 27.0 MM |
| Hat Finish | Painted |
| Overall Height | 1.83 IN |
| Outside Diameter | 226.0 MM |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 2.65 IN |
| Mounting Bolt Hole Circle Diameter | 120.0 MM |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 15.700 MM |
| California Proposition 65 Text [basic] | WARNING: Cancer and Reproductive Harm |
| Disc Mounting [cntrc] | Floating |
| Hat Id [cntrc] In | 5.571 |
| Hat Id [cntrc] Mm | 141.500 |
| Misc Holes [cntrc] | 1 |
| Weight [cntrc] Kgs | 4.580 |
| Weight [cntrc] Lbs | 10.100 |
| Product Grade [cntrc] | Premium |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Material | Cast Iron |
| Discard Thickness | 0.98 IN |
| Nominal Thickness | 1.06 IN |
| Maximum Brake Diameter (Discard) | 349.90 MM |
| Rust Resistant Coating | Yes |
| Inside Diameter | 8.90 IN |
| Inside Diameter | 226.0 MM |
| Overall Height | 46.50 MM |
| Outside Diameter | 8.90 IN |
| Mounting Bolt Hole Quantity | 5 |
| Center Hole Diameter | 67.40 MM |
| Mounting Bolt Hole Circle Diameter | 4.72 IN |
| Mounting Bolt Hole Diameter | 0.63 IN |
| Mounting Bolt Hole Diameter | 16.0 MM |
| Stud/Lug Hole Diameter | 0.618 IN |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
Additional Information
| Country of Origin (Primary) | CN |
| NAFTA Preference Criterion Code | B |
| UPC | 00889590356892 |
CENTRIC 125.39061 Cross References
CENTRIC 125.39061 Fits Vehicles
- Volvo XC40 (2019-2023)
