*Representative image - actual part not displayed
Centric 120.58024 - Centric Premium Brake Rotor
$4449
5 day lead time
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
Product Attributes
| Vane Style [cntrc] | Straight |
| Misc Holes [cntrc] | 5 |
| Hat Id [cntrc] In | 6.512 |
| Weight [cntrc] Lbs | 18.850 |
| Disc Mounting [cntrc] | Floating |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Hat Id [cntrc] Mm | 165.400 |
| Weight [cntrc] Kgs | 8.550 |
| OEM Vane Count [cntrc] | 45 |
| Product Grade [cntrc] | Premium |
| Discard Thickness | 22.400 MM |
| Discard Thickness | 0.882 IN |
| Nominal Thickness | 24.000 MM |
| Nominal Thickness | 0.945 IN |
| Hat Finish | Coated |
| Overall Height | 55.900 MM |
| Overall Height | 2.201 IN |
| Outside Diameter | 330.000 MM |
| Outside Diameter | 12.992 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 72.000 MM |
| Center Hole Diameter | 2.835 IN |
| Mounting Bolt Hole Circle Diameter | 127.000 MM |
| Mounting Bolt Hole Circle Diameter | 5.000 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 17.000 MM |
| Stud/Lug Hole Diameter | 0.669 IN |
Additional Information
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00889590323788 |
Part Interchanges
CENTRIC 120.58024 Cross Reference
We have 3 alternatives for the 120.58024 by CENTRIC:
Fits Vehicles
- Jeep Wrangler (2018-2023)
