DELPHI part description

Product Description

Control Arm and Ball Joint Assembly

Product Attributes

Item Grade Standard Replacement
Position(s) Front Left Lower
Pre-Greased Yes
Grease Fitting Included No
Bushings Included Yes
Ball Joint Mounting Type Bolt In
Ball Joint Stud Type Threaded
Control Arm Material Aluminum
Mounting Hardware Included Yes
Adjustable No
Greasable No
Control Arm Maximum Width 14.590 IN
Control Arm Maximum Length 19.630 IN
Bushing Material Rubber
Control Arm Color Gray
Thread Direction Clockwise (Right)
Bushing Color Black
Dust Boot Included Yes
Ball Joint Included Yes
Control Arm Construction Casting/Forged
Grade Type Premium
Boot Material Chloroprene Rubber (CR)
Locking Nut Included Yes
Control Arm Maximum Width 370.59 MM
Control Arm Maximum Length 498.60 MM
Boot Color Black
Steering Type Power
Bearing Material Plastic
Dust Boot Material Chloroprene Rubber (CR)

Additional Information

Harmonized Tariff Code (Schedule B) 8708807000
Harmonized Tariff Code (HTS) 8708806590
Warranty Special Limited Lifetime
Warranty Special UOM LF
Country of Origin (Primary) TR
UPC 00689604368497
VMRS Code 016001001
UNSPSC 25172013

Part Interchanges

Fits Vehicles

  • Volkswagen Passat CC (2009-2010)
  • Volkswagen CC (2009-2017)
  • Volkswagen Tiguan (2009-2010)
  • Volkswagen Passat (2006-2010)
