CENTRIC 122.66045 Part Description
Manufacturer
Product Description
Centric Premium Brake Drum
Features & Benefits
- OE style castings ensure superior performance and extended service life. Machined finishes provide cleaner appearance through wheels. Precision machined friction surfaces ensure smooth operation and reduced noise
CENTRIC 122.66045 Specifications
Product Attributes
| Misc Holes [cntrc] | 2 |
| Weight [cntrc] Kgs | 11.182 |
| Weight [cntrc] Lbs | 24.600 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 139.700 |
| Bolt Circle Diameter [cntrc] In | 5.500 |
| Hub Hole / Register [cntrc] Mm | 78.600 |
| Hub Hole / Register [cntrc] In | 3.094 |
| Height [cntrc] Mm | 96.520 |
| Height [cntrc] In | 3.800 |
| Friction Surface Width [cntrc] Mm | 76.200 |
| Friction Surface Width [cntrc] In | 3.000 |
| Product Grade [cntrc] | Premium |
| Maximum Brake Diameter (Discard) | 296.500 MM |
| Maximum Brake Diameter (Discard) | 11.673 IN |
| Bolt Hole Quantity | 6 |
| Outside Diameter | 335.500 MM |
| Outside Diameter | 13.209 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 16.500 MM |
| Mounting Hole Diameter | 0.650 IN |
| Nominal Drum Diameter | 295.000 MM |
| Nominal Drum Diameter | 11.614 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 805890531180 |
CENTRIC 122.66045 Part Interchanges
| Brand | Part Number |
|---|---|
| Raybestos Brakes | 9801R |
| N/A | BD180466, E127-71-050, 21118, 122.66045, 02042L2863, 02042M2055, 80128, 1408-274983, YH274983, 21118G, 72008, 22874950, 25832104, 25976967, 9801, PDR0800, 860032, 1771018, 1771133, 36547071, E12771050 |
CENTRIC 122.66045 Fits Vehicles
- GMC Sierra 1500 (2009-2013)
- Chevrolet Silverado 1500 (2009-2013)
CENTRIC 122.66045 Cross References
We have 1 alternatives for the 122.66045 by CENTRIC:
