(888) 312-8812 Login SignupCENTRIC 121.65022 C-Tek Standard Brake Rotor
Tap to view 4 more
$15649
Limited availability at this price!
In Stock
Get it by Tuesday, Jan 6
CENTRIC 121.65022 Part Description
Manufacturer
Product Description
C-Tek Standard Brake Rotor
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
CENTRIC 121.65022 Specifications
Product Attributes
| Inner Race # [cntrc] | 416.68003 |
| Weight [cntrc] Lbs | 35.140 |
| Misc Holes [cntrc] | 0 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Outer Bearing # [cntrc] | 415.68002 |
| Inner Seal # [cntrc] | 417.65008 |
| Inner Bearing # [cntrc] | 415.68004 |
| Vane Style [cntrc] | Straight |
| Weight [cntrc] Kgs | 15.970 |
| Outer Race # [cntrc] | 416.68001 |
| Disc Mounting [cntrc] | Hub & Rotor |
| Product Grade [cntrc] | Standard |
| Discard Thickness | 29.970 MM |
| Discard Thickness | 1.180 IN |
| Nominal Thickness | 31.620 MM |
| Nominal Thickness | 1.245 IN |
| Stud Thread Diameter | 0.500 IN |
| Overall Height | 130.600 MM |
| Overall Height | 5.142 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Rotor Outside Diameter | 319.000 MM |
| Rotor Outside Diameter | 12.559 in |
| Solid Or Vented Type Rotor | Vented |
| Bolt Thread Pitch | 20.000 IN |
| Bearings Included | No |
| Center Hole Diameter | 84.600 MM |
| Center Hole Diameter | 3.331 IN |
| Mounting Bolt Hole Circle Diameter | 165.100 MM |
| Mounting Bolt Hole Circle Diameter | 6.500 IN |
| Stud/Lug Hole Quantity | 8 |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 805890050452 |
CENTRIC 121.65022 Part Interchanges
| Brand | Part Number |
|---|---|
| N/A | BD60469, E126-70-027, 5426, BR5426, 5426G, D6TZ1102B, 102260, 141154, PRT1154, 85601, 4885601, 531, AR8522, AR8522E, D6052, E12670027, E8373, 121.65022, X50128, BR1056, 6052, 6052R, 8942022, 78-42022, 7842022, 78942022, 60054114, 177591 |
CENTRIC 121.65022 Fits Vehicles
- Ford E-200 Econoline (1973-1974)
- Ford F-250 (1976-1979)
- Ford E-250 Econoline Club Wagon (1975-1980)
- Ford E-250 Econoline (1975-1980)
CENTRIC 121.65022 Cross References
We have 3 alternatives for the 121.65022 by CENTRIC:
