(888) 312-8812 Login SignupWABCO 4722600110 Air Brake Valve - Proportional Valve - 24V, 570 Ma, Bayonet
Tap to view 3 more
MSRP: $1,681.28
$1,61949
Save $61.79
Limited Availability
Due to limited availability, we will confirm your order and notify you within 1 business day.
WABCO 4722600110 Part Description
WABCO 4722600110 Specifications
Product Attributes
| Size | 201 x 113 x 71 |
| Voltage | 24 V |
| Mounting | 4x Ø 8.5 |
| Distance Between Holes | 54x84.5 mm |
| Nominal Diameter | 8.0 mm |
| Max. operating pressure | 174 psi |
| Temperature Range | -20°C to +110°C |
| Weight | 3.5186 |
| Port thread 31 | Flap Exhaust |
| Port thread 1 | M22 x 1.5 JED-152 |
| Calculated Volume (dm³) | 1.6126 |
| Electrical connection | Bayonet DIN 72585 B1-2.1-1-Sn/K1 |
| Max. operating pressure | 174 psi |
| Protection class | IP 67 / IP 6K9K |
| Port thread 32 | Ø 15 mm |
| Port thread 2 | Ø 15 mm |
WABCO 4722600110 Cross References
| Brand | Part Number |
|---|---|
| MERITOR | S4722600110 |
WABCO 4722600110 Customer Reviews
No reviews yet
Be the first to review this product!
WABCO 4722600110 Manufacturer Information
Whether it’s for cars, buses, trucks, or trailers, WABCO® is at the frontline at developing and providing products and systems to make vehicles safer and easier to control. Founded in 1869, WABCO is a major supplier of braking, stability, suspension and transmissions in the Americas and beyond. The company is recognized as introducing the modern air brake system in 1869, and continues to lead the industry in air brake design and production for the heavy duty and commercial vehicle sectors. Today, WABCO operates as a division of the German auto parts maker ZF and employs 16,000 employees in facilities in 36 countries worldwide.
