GATES part description

Product Description

PoweRated FHP Medium Horse-Power V-Belt

Application Summary

1985-1984 Mazda, 626, 4-Cyl. 2.0 L Diesel, Alt. & A.C.

Features & Benefits

  • Designed with distinct green color bareback construction for smooth clutching on shock loaded, backside idler-driven equipment to ensure high crack resistance
  • Low, aramid tensile cord positioned in a thin profile gives extreme flexibility and limited stretch with extraordinary strength and durability
  • Meets RMA oil and heat-resistant standards, but not for static conductivity
  • Temperature Range: -22 Deg. F to +140 Deg. F (-30 Deg. C to +60 Deg. C)
  • Note: Gates PoweRated V-belts can be substituted for equivalent sizes of FHP low horsepower Gates Truflex V-belts

Product Attributes

Type FHP Medium Horse-Power V-Belt
Cross Section Designation 5L
Angle 35
Strand Quantity 1
Top Width .66 in
Outside Circumference 29 in
Effective Length 29.16 in
Construction Wrapped
9837 No
Belt Material EPDM
Cord Material Aramid
Top Width 17 mm
Outside Circumference 737 mm
Effective Length 741 mm

Additional Information

Harmonized Tariff Code (Schedule B) 4010323000
Country of Origin (Primary) MX
UPC 00072053005097
VMRS Code 065005003
UNSPSC 26111801

Part Interchanges

Fits Vehicles

  • Gardner Model 8-85 (1928)
  • Gardner Model 8-75 (1928)
  • Nash Light Six (1925)
  • Auburn Model 8-77 (1927-1928)
  • Mazda 626 (1984-1985)
