(888) 312-8812 Login SignupGATES 26520 VULCO-FLEX HOSE
SHIPS TODAY
$3149
Limited availability at this price!
In Stock
Get it by Monday, Jan 26
GATES 26520 Part Description
Manufacturer
Product Description
Green Stripe Heavy-Duty Vulco-Flex Coolant Hose
Application Summary
1988-1980 GMC, Brigadier, Detroit Diesel 6-71 Diesel, Lower - Pipe To Rad.
Features & Benefits
- Engineered to resist electrochemical degradation, the leading cause of hose failure
- Built-in steel spiral wire allows for medium sized curves without kinking or collapsing
- EPDM tube and Neoprene cover for extended service life
- Polyester fabric-ply reinforcement vulcanizes into shape without unnecessary strain on connections
- Resistant to heat, oil and ozone
- Performs to SAE 20R5 Type EC Class D-2 specifications
- Temperature Range: -40 Deg. F to +257 Deg. F (-40 Deg. C to +125 Deg. C)
- Caution: Do not use for fuel or oil transfer applications
GATES 26520 Specifications
Product Attributes
| Centerline Length | 11 IN |
| End 1 Inside Diameter | 2.25 in |
| End 2 Inside Diameter | 2.25 in |
| Material | EPDM, Steel |
| Molded | No |
| Centerline Length | 279 MM |
| End 1 Inside Diameter | 57 MM |
| End 2 Inside Diameter | 57 MM |
Additional Information
| Country of Origin (Primary) | MX |
| Harmonized Tariff Code (Schedule B) | 4009410000 |
| UPC | 00072053064902 |
| VMRS Code | 042004061 |
| UNSPSC | 40142000 |
GATES 26520 Cross References
| Brand | Part Number |
|---|---|
| 42840103 | |
| <Unknown> | 11864F, 552481, M19204F |
| ACDelco | 31719 |
| BF Goodrich | 911 |
| CARQUEST | 26520 |
| CONTINENTAL AG | 53611 |
| Caterpillar | A628392C2 |
| Chrysler | 2514228 |
| Continental Belt | 53611 |
| Dayco | 2111HD, 82171, 82171GL, M55 |
| Diamond Reo | N19204E, N19204F, N91204AK |
| Durkee-Atwood | 911 |
| Epton | 911 |
| Ford | C3TA 8286 A, C3TZ 8286 A, C9HS 8286 E, D0HA 8286 BL, D0HA 8286 BM |
| General Motors | 2061328, 2462750, 2463651, 2490312, 2490332, 332998, 2069767 |
| Goodyear | 53611 |
| International Harvester (IHC) | 199174, 276119C1, 276119C22, 336663R1, 423961C1 |
| Mack | 10MF29301P11, 11MF2320P10, 11MF2320P13, 11MF2320P17 |
| Mopar | BH-637 |
| Motorcraft | KE-110 |
| N. P. Nelson | C423611 |
| NAPA Belts/Hose | FM55 |
| Reo Trucks | 972F228, 972F266 |
| Volvo GM Heavy Truck | V1092200 |
| Westinghouse | WA7817 |
| White | 1700824, 1710974, 1712875, 664856 |
GATES 26520 Fits Vehicles
- Mack CM (1991)
- GMC Brigadier (1981-1988)
- White WIM (1984)
- White/GMC WCM (1988)
- White/GMC WCL (1988)
- White WCL (1982-1988)
- White WCA (1988)
- White/GMC J9C0 (1988-1989)
- White WCS (1981-1988)
- White WCM (1981-1988)
- White/GMC WCS (1988)
- White/GMC WCA (1988)
- GMC General (1985-1988)
