(888) 312-8812 Login SignupOE form, fit & function wheel hub unit.
| Flange Bolt Hole Quantity | 4 |
| Wheel Pilot Diameter | 4.880 IN |
| Brake Pilot Diameter | 5.000 IN |
| Wheel Stud Quantity | 8 |
| Flange Shape | Modified Rectangular |
| Anti Lock Braking System | Yes |
| Anti Lock Braking System Type | Tone Ring |
| Drive Type | Non-driven |
| Flange Offset | 2.910 IN |
| Bolt Circle Diameter | 7.090 IN |
| Knuckle Bolt Circle Diameter (Inches) | 5.830 |
| Knuckle Bolt Circle Diameter (Millimeters) | 148.0 |
| Knuckle Bolt Hole Size | M14X1.5 |
| Wheel Stud Size | M14X1.5 MM |
| Country of Origin (Primary) | KR |
| Harmonized Tariff Code (Schedule B) | 8708998115 |
| Warranty Time | 12 |
| Warranty Time UOM | MO |
| UPC | 662810618471 |
| Brand | Part Number |
|---|---|
| SKF | BR930830 |
| Timken | SP620300 |
| Mevotech | H515147 |
| MOOG Chassis Products | 515147 |
| General Motors | 84459700, 20873259, 22762441, 25807421 |
| ACDelco | FW387 |
| Schaeffler | 102238 |
| Autopart International | 1411-480973 |
| WJB | WA515147 |
| GMB | 7303220 |
Be the first to review this product!
