NTN WE61627 - Wheel Bearing and Hub Assembly - Steel, Natural, with Wheel Studs
$39649
Limited Availability
Pay over 3-12 months with . Learn more
NTN part description
Product Description
OE form, fit & function wheel hub unit.
Features & Benefits
- All BCA applications that require ABS functionality utilize our custom-designed seals that are molded over with magnetic encoders (if required) to ensure proper ABS operation.
- Forged-steel construction provides the toughness and durability required for even the harshest applications.
- Rolling element cages reduce friction by keeping rolling elements spaced correctly, preventing damage and resulting in reduced operational temperatures.
- Application-specific components to ensure proper connection and performance of the ABS module and sensors.
- Pre-lubricated bearings, sealed for life with specialized grease provide longer life and a wider range of operational temperatures.
- Application-specific engineering reduces noise, vibration and harshness (NVH).
Product Attributes
Flange Included | Yes |
Flange Bolt Hole Quantity | 3 |
Wheel Pilot Diameter | 2.760 IN |
Brake Pilot Diameter | 2.780 IN |
Wheel Stud Quantity | 5 |
Drive Type | Non-driven |
Bearing Type | Ball |
Flange Offset | 1.657 IN |
Flange Diameter | 145.5 MM |
9555 | 4.752 IN |
Bearing Generation | Gen 3 |
Knuckle Bolt Hole Size | M12X1.75 |
Knuckle Pilot Hole Diameter | 3.598 |
Wheel Stud Size | M12X1.5 MM |
Additional Information
Country of Origin (Primary) | US |
Harmonized Tariff Code (Schedule B) | 8708995800 |
Warranty Time | 12 |
Warranty Time UOM | MO |
UPC | 662810616279 |
Part Interchanges
- Mevotech H513291
- General Motors 19208046
- General Motors 12413306
- General Motors 7467851
- GMB 7300009
- Raybestos Brakes 713291
- Drive Tech America NT513291
- Alltech Automotive 513291
- CRS Automotive NT513291
- SKF BR930756
- Timken HA590388
- MOOG Chassis Products 513291
- Centric Parts 407.62026
- ACDelco FW370
- Schaeffler 102233
- DT Components 513291
- Autopart International 1411423159
- Fenco WH513291
- MPA WH513291
- WJB WA513291
- Centric Parts 407.62026E
Fits Vehicles
- Chevrolet Corvette (2009-2013)
- Cadillac XLR (2009)
