NTN WE61257 - Wheel Bearing and Hub Assembly - Steel, Natural, with Wheel Studs
$28599
Limited Availability
Pay over 3-12 months with . Learn more
NTN part description
Product Description
OE form, fit & function wheel hub unit.
Features & Benefits
- All BCA applications that require ABS functionality utilize our custom-designed seals that are molded over with magnetic encoders (if required) to ensure proper ABS operation.
- Forged-steel construction provides the toughness and durability required for even the harshest applications.
- Rolling element cages reduce friction by keeping rolling elements spaced correctly, preventing damage and resulting in reduced operational temperatures.
- Application-specific components to ensure proper connection and performance of the ABS module and sensors.
- Pre-lubricated bearings, sealed for life with specialized grease provide longer life and a wider range of operational temperatures.
- Application-specific engineering reduces noise, vibration and harshness (NVH).
Product Attributes
Flange Bolt Hole Quantity | 4 |
Wheel Pilot Diameter | 2.638 IN |
Brake Pilot Diameter | 2.835 IN |
Wheel Stud Quantity | 5 |
Drive Type | Non-driven |
Bearing Type | Ball |
Flange Offset | 2.146 IN |
Flange Diameter | 140 MM |
9555 | 4.500 IN |
Bearing Generation | Gen 3 |
Knuckle Bolt Circle Diameter (Inches) | 3.661 |
Knuckle Bolt Circle Diameter (Millimeters) | 93.0 |
Knuckle Bolt Hole Size | M10X1.25 |
Knuckle Pilot Hole Diameter | 2.913 IN |
Wheel Stud Size | M12x1.5 MM |
Additional Information
Country of Origin (Primary) | CN |
Harmonized Tariff Code (Schedule B) | 8708995800 |
Warranty Time | 12 |
Warranty Time UOM | MO |
UPC | 662810612578 |
Part Interchanges
- Power Train PT590096
- Beck/Arnley 0516434
- Mevotech MB76303
- CRS Automotive NT590096
- Timken HA590096
- MOOG Chassis Products 513341
- Centric Parts 407.45001
- Mazda F1513304X
- DT Components HA590096
- Autopart International 141109820
- Fenco WH590096
- MPA WH590096
- WJB WA590096
- GMB 7450003
- Centric Parts 407.45001E
Fits Vehicles
- Mazda RX-8 (2004-2011)
