NTN WE61214 - Wheel Bearing and Hub Assembly - Steel, Natural, with Wheel Studs
$34899
Limited Availability
Pay over 3-12 months with . Learn more
NTN part description
Product Description
OE form, fit & function wheel hub unit.
Features & Benefits
- All BCA applications that require ABS functionality utilize our custom-designed seals that are molded over with magnetic encoders (if required) to ensure proper ABS operation.
- Forged-steel construction provides the toughness and durability required for even the harshest applications.
- Rolling element cages reduce friction by keeping rolling elements spaced correctly, preventing damage and resulting in reduced operational temperatures.
- Application-specific components to ensure proper connection and performance of the ABS module and sensors.
- Pre-lubricated bearings, sealed for life with specialized grease provide longer life and a wider range of operational temperatures.
- Application-specific engineering reduces noise, vibration and harshness (NVH).
Product Attributes
Spline Quantity | 30 |
Flange Bolt Hole Quantity | 3 |
Wheel Pilot Diameter | 65.0 MM |
Brake Pilot Diameter | 70.0 MM |
Wheel Stud Quantity | 5 |
Flange Shape | Triangle |
Anti Lock Braking System | Yes |
Drive Type | Driven |
Flange Offset | 39.0 MM |
Flange Diameter | 5.394 IN |
9555 | 110.0 MM |
Anti Lock Braking System Type | Encoder with sensor |
Bearing Generation | 3 |
Knuckle Bolt Circle Diameter (Inches) | 4.016 |
Knuckle Bolt Circle Diameter (Millimeters) | 102.0 |
Wheel Stud Size | M12X1.5 MM |
Additional Information
Country of Origin (Primary) | DE |
Harmonized Tariff Code (Schedule B) | 8708995800 |
Warranty Time | 12 |
Warranty Time UOM | MO |
UPC | 662810612141 |
Part Interchanges
- Power Train PT513259
- Mevotech H513259
- General Motors 10345966
- GMB 7300410
- Raybestos Brakes 713259
- Drive Tech America NT513259
- Alltech Automotive 513259
- CRS Automotive NT513259
- SKF BR930642
- Timken HA590186
- MOOG Chassis Products 513259
- Centric Parts 402.62020
- ACDelco FW280
- ACDelco 513259
- Schaeffler FW9259
- Schaeffler 559580
- DT Components 513259
- Autopart International 1411246651
- MPA WH513259
- WJB WA513259
- Centric Parts 402.62020E
Fits Vehicles
- Saturn Sky (2007-2010)
- Pontiac Solstice (2006-2009)
