(888) 312-8812 Login SignupNTN WE60791 Wheel Bearing and Hub Assembly - Steel, Natural, with Wheel Studs
Tap to view 9 more
$22499
Limited Availability
Due to limited availability, we will confirm your order and notify you within 1 business day.
NTN WE60791 Part Description
Manufacturer
Product Description
OE form, fit & function wheel hub unit.
Features & Benefits
- All BCA applications that require ABS functionality utilize our custom-designed seals that are molded over with magnetic encoders (if required) to ensure proper ABS operation.
- Forged-steel construction provides the toughness and durability required for even the harshest applications.
- Rolling element cages reduce friction by keeping rolling elements spaced correctly, preventing damage and resulting in reduced operational temperatures.
- Application-specific components to ensure proper connection and performance of the ABS module and sensors.
- Pre-lubricated bearings, sealed for life with specialized grease provide longer life and a wider range of operational temperatures.
- Application-specific engineering reduces noise, vibration and harshness (NVH).
NTN WE60791 Specifications
Product Attributes
| Flange Bolt Hole Quantity | 4 |
| Wheel Pilot Diameter | 2.126 IN |
| Brake Pilot Diameter | 2.165 IN |
| Wheel Stud Quantity | 5 |
| Flange Shape | Modified Rectangular |
| Drive Type | Non-driven |
| Bearing Type | Ball |
| Flange Offset | 2.146 IN |
| Flange Diameter | 135 MM |
| Bolt Circle Diameter | 3.937 IN |
| Bearing Generation | Gen 3 |
| Knuckle Bolt Circle Diameter (Inches) | 3.661 |
| Knuckle Bolt Circle Diameter (Millimeters) | 93.0 |
| Knuckle Bolt Hole Size | M10X1.25 |
| Knuckle Pilot Hole Diameter | 2.913 IN |
| Wheel Stud Size | M12X1.5 MM |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 8482105016 |
| Warranty Time | 12 |
| Warranty Time UOM | MO |
| UPC | 662810607918 |
NTN WE60791 Cross References
| Brand | Part Number |
|---|---|
| ACDelco | RW2077, 512217 |
| Autopart International | 141149103 |
| Beck/Arnley | 0516160, 0516265 |
| CENTRIC | 407.44012 |
| Centric Parts | 407.44006, 407.44012, 407.44012E |
| DT Components | 512217 |
| Drive Tech America | NT512217 |
| DuraGo | 29512217 |
| Fenco | WH512217 |
| GMB | 7700316 |
| GSP | 103217 |
| General Motors | 88970098 |
| MOOG Chassis Products | 512217 |
| MPA | WH512217 |
| Mevotech | H512217, H512215 |
| Parts Master | PM512217 |
| Parts Plus | P512217 |
| Power Train | PT512217 |
| Raybestos Brakes | 712217 |
| SKF | BR930324 |
| Schaeffler | 102503, RW8215, RW8217 |
| Timken | HA590055, 512217, HA590040 |
| Toyota | 4245001010, 4245002070, 4245001020, 4245047030 |
| WJB | WA512217 |
NTN WE60791 Fits Vehicles
- Toyota Prius (2004-2009)
- Toyota Matrix (2003-2008)
- Toyota Corolla (2003-2008)
- Pontiac Vibe (2003-2008)
