NTN WE60718 - Wheel Bearing and Hub Assembly - Steel, Natural, with Wheel Studs
$16899
Limited Availability
Pay over 3-12 months with
. Learn more
. Learn more
NTN part description
Product Description
OE form, fit & function wheel hub unit.
Features & Benefits
- All BCA applications that require ABS functionality utilize our custom-designed seals that are molded over with magnetic encoders (if required) to ensure proper ABS operation.
- Forged-steel construction provides the toughness and durability required for even the harshest applications.
- Rolling element cages reduce friction by keeping rolling elements spaced correctly, preventing damage and resulting in reduced operational temperatures.
- Application-specific components to ensure proper connection and performance of the ABS module and sensors.
- Pre-lubricated bearings, sealed for life with specialized grease provide longer life and a wider range of operational temperatures.
- Application-specific engineering reduces noise, vibration and harshness (NVH).
Product Attributes
| Spline Quantity | 27 |
| Flange Bolt Hole Quantity | 3 |
| Wheel Pilot Diameter | 2.760 IN |
| Brake Pilot Diameter | 2.776 IN |
| Wheel Stud Quantity | 5 |
| Flange Shape | Modified Triangle |
| Anti Lock Braking System | Yes |
| Anti Lock Braking System Type | Tone Ring |
| Drive Type | Driven |
| Flange Offset | 1.858 IN |
| 9555 | 4.757 IN |
| Knuckle Bolt Hole Size | M10X1.5 |
| Wheel Stud Size | M12X1.5 MM |
Additional Information
| Country of Origin (Primary) | KR |
| Harmonized Tariff Code (Schedule B) | 8708995800 |
| Warranty Time | 12 |
| Warranty Time UOM | MO |
| UPC | 662810607185 |
Part Interchanges
- Power Train PT513124
- Beck/Arnley 0516170
- Mevotech TXF513124
- Mevotech H513124
- General Motors 12413045
- General Motors 19150096
- General Motors 7470537
- General Motors 7470608
- General Motors 12413046
- General Motors 7467139
- General Motors 7470607
- GMB 7300001
- Raybestos Brakes 713124
- Drive Tech America NT513124
- DuraGo 29513124
- GSP 104124
- CRS Automotive NT513124
- Dorman 4110303
- Precision Bearing 513124
- Magneti Marelli 1AMH513124
- Isuzu 8124130450
- SKF BR930097
- Timken 513124
- MOOG Chassis Products 513124
- Centric Parts 402.66006
- Centric Parts 402.66006E
- ACDelco FW127
- ACDelco 513124
- Parts Master PH513124
- Schaeffler 102029
- Schaeffler FW9124
- DT Components 513124
- Autopart International 141145585
- Fenco WH513124
- MPA WH513124
- Parts Plus P513124
- WJB WA513124
Fits Vehicles
- Oldsmobile Bravada (1997-2001)
- GMC Sonoma (1998-2004)
- GMC Jimmy (1998-2000)
- Chevrolet S10 (1998-2004)
- Chevrolet Blazer (1998-2005)
- Isuzu Hombre (1998-2000)
